Description
Product Overview
The 7400209-030 DO2401 Digital Output Baseplate from Triconex delivers high-density, fault-tolerant output control for Tricon v10–v11 safety systems. This 32-channel module supports 24–48VDC outputs at 500mA per channel, making it ideal for emergency shutdown and turbine protection systems.
Each output channel in the 7400209-030 DO2401 features optical isolation rated at 1500V AC/DC, preventing signal interference in electrically noisy environments. The module’s triple-modular redundant (TMR) architecture ensures continuous operation even during hardware faults.
Engineers can configure fail-safe states per channel, enhancing reliability in fire/gas and critical shutdown applications. The module supports hot-swappable replacement, allowing maintenance without interrupting system operations.
LED indicators and TRISTATION 1131 software provide real-time diagnostics and fault detection. The 7400209-030 DO2401 operates across a wide -40°C to +70°C range, ensuring performance in extreme industrial conditions.
Technical Specifications
| Parameter |
Specification |
| Model Number |
7400209-030 DO2401 |
| Manufacturer |
Triconex |
| Product Range |
Tricon Systems |
| Module Type |
Digital Output Baseplate |
| System |
DCS |
| Channels |
32 Isolated Digital Outputs |
| Output Voltage |
24–48V DC |
| Output Current |
500mA per channel |
| Architecture |
Triple-Modular Redundant (TMR) |
| Isolation Rating |
1500V AC/DC per channel |
| Diagnostics |
LED indicators, TRISTATION 1131 |
| Fail-Safe Config |
Per-channel programmable |
| Response Time |
≤ 50 milliseconds |
| Certifications |
IEC 61508 SIL3, ATEX, cULus |
| Operating Temp. |
-40°C to +70°C |
| Dimensions |
26.8 × 17.8 × 8 cm |
| Weight |
1.34 kg |
| HS Code |
8537101190 |
| Communication |
Ethernet Router |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Discontinued |
Active |
Applications & Compatibility
The 7400209-030 DO2401 integrates seamlessly with Triconex TMR systems and supports:
-
Emergency Shutdown (ESD) valves
-
Fire and gas detection systems
-
Turbine and compressor protection
-
Chemical, pharmaceutical, and offshore safety systems
