Description
Product Overview
The 3703E Analog Input Module from Triconex delivers high-speed, precision voltage measurement for industrial control systems. Built for Tricon System platforms, this module features four analog input channels that measure voltages from -10V to +10V with exceptional accuracy.
Engineers rely on the 3703E for its 500Hz sampling rate, enabling fast and responsive data acquisition for real-time monitoring. Its low power consumption—less than 2.5W—supports energy-efficient operations without compromising performance.
The module operates reliably in extreme conditions, withstanding temperatures from -40°C to +70°C and humidity up to 95% RH (non-condensing). Its rugged design ensures long-term stability in harsh environments such as oil, gas, and chemical processing.
Technical Specifications
| Parameter |
Specification |
| Model Number |
3703E |
| Manufacturer |
Triconex |
| Product Range |
Tricon System |
| Module Type |
Analog Input Module |
| System |
DCS |
| Input Channels |
4 Analog Inputs |
| Input Voltage Range |
-10V to +10V |
| Sampling Rate |
500Hz |
| Power Consumption |
< 2.5W |
| Operating Temp. |
-40°C to +70°C |
| Humidity Tolerance |
Up to 95% RH (non-condensing) |
| Dimensions |
49 × 45.3 × 6.8 cm |
| Weight |
3.2 kg |
| HS Code |
8537101190 |
| Communication |
Ethernet Router |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
Applications & Compatibility
The 3703E integrates with Tricon controllers and supports:
-
Real-time voltage monitoring
-
Process control in oil and gas systems
-
Temperature and flow signal acquisition
-
Safety Instrumented Systems (SIS) requiring analog input
