Configured for redundant power and signal path coordination in Honeywell control system network architectures, the Honeywell TK-PRR021 51309288-275 (TK-PRR021 Redundancy Module) provides direct physical/electrical execution for redundancy management and module synchronization functions.
Hardware Specifications
Parameter
Specification
Model
TK-PRR021 51309288-275
Brand
Honeywell
Product Type
Redundancy Module
Origin
USA
Weight
0.46 kg
Dimensions
6.9 x 14.1 x 14.5 cm
Operating Temp
-20 deg C to +70 deg C
Storage Temperature
-40 deg C to +85 deg C
Relative Humidity
5-95% non-condensing
Power Supply
24 VDC +/-10%
Power Consumption
5 W typical, 8 W maximum
Synchronization Speed
100 Mbps full duplex
Isolation Voltage
1500 V AC
Current Range
0.75-1 A / 7-90 mA
Voltage Range
3.3-24 VDC
Tariff Code
8537101190
Manufacturer
Honeywell
Shipment Location
Xiamen, China
Process Control Redundancy and Signal Isolation Characteristics
The TK-PRR021 51309288-275 supports redundant module operation by maintaining synchronized communication paths and power distribution conditions. Moreover, the module uses full duplex 100 Mbps communication to exchange redundancy status data between connected control components.
For Honeywell process control hardware environments, the module architecture aligns with DCS electrical design requirements, including channel-to-channel isolation concepts and controlled signal separation. Therefore, the 1500 V AC isolation rating helps reduce electrical interference between connected circuits.
In addition, the module supports 24 VDC power input operation with defined consumption limits. The 5 W typical and 8 W maximum power values allow system engineers to calculate cabinet power loading and thermal conditions during panel design.
Frequently Asked Questions
Q: What power input does the Honeywell TK-PRR021 51309288-275 require? A: The module requires a 24 VDC power supply with an allowable range of +/-10%.
Q: Does the TK-PRR021 support high-speed synchronization communication? A: Yes. The module provides 100 Mbps full duplex synchronization communication for redundancy coordination.
Q: What isolation capability is specified for this redundancy module? A: The module specifies 1500 V AC isolation between applicable electrical sections.
Field Installation Guidelines
Install the TK-PRR021 51309288-275 in a compatible Honeywell control cabinet position according to the system hardware configuration requirements.
Verify the 24 VDC supply polarity and voltage range before connecting field wiring.
Keep power wiring separated from high-current switching circuits to reduce electrical interference.
Use appropriate grounding methods for cabinet installation and maintain clean signal reference paths.
Confirm communication cable routing before system commissioning to prevent unnecessary electromagnetic coupling.
Check module status indicators and redundancy communication conditions after installation.
