Honeywell TK-PPD011 51309241-175 Battery Extension Module The Honeywell TK-PPD011 51309241-175, also cataloged as the 51309241-175 Battery Extension Module, operates as...
Read more
SKU: TK-PPD011 51309241-175 51204142-100
Country of origin: USA
The Honeywell TK-PPD011 51309241-175, also cataloged as the 51309241-175 Battery Extension Module, operates as a dedicated hardware component for extending backup power capacity within Honeywell Experion PKS controller power architectures.
The Honeywell TK-PPD011 51309241-175 integrates into Honeywell controller backup power structures to maintain controller memory retention and support controlled system recovery after power interruptions. Moreover, the module provides auxiliary battery capacity for automation assemblies that require extended backup operation.
The module uses a 24 VDC nominal supply interface and supports internal controller power requirements through a compact battery extension design. In addition, the TK-PPD011 supports Honeywell control architectures including C200, C300, ControlEdge PLC, and compatible safety control platforms.
For process control applications, the module operates as a dedicated backup power component rather than a signal acquisition device. Therefore, installation requires correct integration with the existing controller power distribution and battery management configuration.
Frequently Asked Questions
Q: What is the primary electrical function of the Honeywell TK-PPD011 51309241-175? A: The module extends battery backup capacity for Honeywell controller assemblies and supports memory retention functions during primary power loss.
Q: Does the TK-PPD011 provide industrial communication functions? A: No. The TK-PPD011 is a battery extension component and does not operate as a communication interface or I/O signal module.
Q: What voltage interfaces are supported by the module? A: The module supports 24 VDC nominal operation and also supports 5 VDC system compatibility according to controller architecture requirements.
Field Installation Guidelines
Install the TK-PPD011 within the designated Honeywell controller power and battery backup assembly location.
Verify polarity and voltage compatibility before connecting the module to the power distribution circuit.
Keep battery power wiring separated from high-voltage AC cables and high-current switching conductors.
Maintain proper cabinet grounding practices according to the control system installation requirements.
Inspect terminal connections and cable routing to prevent mechanical stress on power interfaces.
Confirm controller backup operation after installation through the applicable Honeywell system
