Description

Honeywell TC-PCIC01K ControlNet PCI Communication Interface Card

The Honeywell TC-PCIC01K, also cataloged as the TC-PCIC01K ControlNet PCI Communication Interface Card, operates as a dedicated hardware component for PCI-based host communication with ControlNet networks within Honeywell Experion PKS and PlantScape system platforms.

Hardware Specifications

Parameter	Specification
Model	TC-PCIC01K
Brand	Honeywell
Product Type	ControlNet PCI Communication Interface Card
Network Interface	ControlNet coaxial network interface
Bus Interface	32-bit PCI bus
Connectors	Dual BNC connectors for redundant ControlNet channels
Communication Rate	5 Mbps
Protocol	ControlNet scheduled and unscheduled messaging
Topology Support	Trunkline/dropline, star, and ring configurations through network accessories
Operating Temp	0 deg C to 60 deg C
Storage Temp	-40 deg C to 85 deg C
Relative Humidity	5% to 95% non-condensing
Weight	0.28 kg
Dimensions	3.5 x 14 x 17.2 cm (estimated shipping size)
Power Consumption	PCI bus supplied power; exact consumption not specified
Slot Compatibility	Standard 32-bit PCI slot, typically 5 V signaling

Process Control Network Communication Characteristics

The TC-PCIC01K provides PCI-bus communication between an industrial host computer and ControlNet field networks. The interface card transfers scheduled and unscheduled ControlNet messages through coaxial media connections and maintains communication synchronization with connected ControlNet nodes.

For Honeywell process control applications, network integration may include interfaces with DCS I/O systems, controller nodes, and supervisory computer platforms. The card supports deterministic ControlNet communication behavior required for cyclic process data exchange.

The module architecture is compatible with process instrumentation communication environments where channel-to-channel isolation, controlled signal transmission, and stable network timing are required. The ControlNet physical layer operates independently from analog instrumentation loops such as 4-20 mA HART protocol channels and FOUNDATION Fieldbus segments.

Frequently Asked Questions

Q: Does the TC-PCIC01K support redundant ControlNet communication media?
A: Yes. The interface card provides dual BNC connectors for ControlNet channel A and channel B connections, allowing connection to redundant coaxial ControlNet network segments.

Q: Can the TC-PCIC01K be installed in a modern PCI Express slot?
A: No. The module is designed for standard PCI bus architecture. A compatible PCI interface is required unless a validated industrial adapter solution is used.

Q: Does the TC-PCIC01K require external field power wiring?
A: No. The interface card receives operating power through the host PCI bus. External ControlNet coaxial connections provide network communication only.

Field Installation Guidelines

• Install the TC-PCIC01K in a compatible PCI expansion slot within the host industrial computer.
• Verify PCI slot mechanical compatibility and system hardware requirements before installation.
• Connect ControlNet coaxial cables to the designated BNC channel connectors according to the network design.
• Maintain proper cable routing separation between ControlNet coaxial wiring and high-voltage power conductors to reduce electrical interference.
• Ensure coaxial cable shielding continuity and proper grounding practices throughout the ControlNet installation.
• Confirm network termination, media connections, and node addressing before placing the communication network into service.
• Follow Honeywell Experion PKS or PlantScape system configuration procedures for software recognition and network parameter setup.

Specifications

• Brand: Honeywell

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
