Honeywell TC-FXX132 13 Slot Chassis Processor Rack Configured for chassis processor housing and 24 VDC power distribution in Honeywell control...
Read more
Configured for chassis processor housing and 24 VDC power distribution in Honeywell control system platforms, the Honeywell TC-FXX132 (TC-FXX132 Rack Chassis Processor) provides direct physical mounting and electrical connection for controller modules and I/O assemblies.
Hardware Specifications
Parameter
Specification
Model
TC-FXX132
Brand
Honeywell
Product Type
Chassis Processor Rack
Origin
USA
Weight
1.68 kg
Dimensions
50.3 x 17.8 x 14.5 cm (shipping size)
Operating Temp
Not specified
Power Consumption
24 VDC, 2.8 A
Slot Capacity
13 Slot Chassis
Function
Processor chassis mounting and module interconnection
Status
Discontinued by manufacturer
Process Control Chassis Integration
The Honeywell TC-FXX132 chassis provides mechanical support and electrical interconnection for processor and I/O assemblies installed within Honeywell control architectures. The rack structure defines module positioning, backplane connectivity, and DC power distribution paths.
For Honeywell process control systems, chassis assemblies are designed to maintain stable communication between installed modules. The rack provides the physical interface required for controller modules, communication interfaces, and related hardware components.
Honeywell chassis hardware typically interfaces with DCS module communication structures using dedicated backplane connections. Channel-to-channel isolation and controlled power distribution are applied at the module level according to the installed system configuration.
Frequently Asked Questions
Q: What is the primary function of the Honeywell TC-FXX132? A: The TC-FXX132 functions as a 13 slot chassis rack for mounting processor and control modules while providing physical support and internal electrical connections.
Q: What power input specification is associated with the TC-FXX132? A: The available specification indicates a 24 VDC power input with a rated current value of 2.8 A.
Q: Can the TC-FXX132 be used as a standalone controller? A: No. The TC-FXX132 is a chassis hardware assembly and requires compatible Honeywell processor and I/O modules to perform control functions.
Field Installation Guidelines
Install the TC-FXX132 chassis on a mechanically stable panel or cabinet mounting surface. Verify that the rack alignment allows correct insertion and removal of processor and I/O modules.
Use suitable industrial wiring practices for the 24 VDC power connection. Separate DC power wiring from high-voltage AC lines and high-current switching conductors to reduce electrical interference.
Connect grounding and shielding according to the control cabinet design requirements. Confirm that module connectors are fully seated before system energization.
Maintain adequate cabinet airflow around installed modules and inspect all mechanical fasteners during commissioning procedures.
