Honeywell TC-CCR012 Redundant Net Interface Module

The Honeywell TC-CCR012, also cataloged as the TC-CCR012 Redundant Net Interface Module, operates as a dedicated hardware component for redundant network communication handling within Honeywell control system network platforms. The module provides the physical interface and electrical connection functions required for redundant communication paths.

Hardware Specifications

Parameter	Specification
Model	TC-CCR012
Brand	Honeywell
Product Type	Redundant Net Interface Module
Origin	United States
Weight	0.3 kg (0 lbs 10.4 oz)
Dimensions	1.3 in x 7.0 in x 5.5 in (3.3 cm x 17.8 cm x 14.0 cm)
Operating Temp	Not specified
Power Consumption	24 VDC current draw: 0.002 A; 5 VDC current draw: 1.000 A
Tariff Code	8517620050
Network Function	Redundant network interface communication
Electrical Supply	24 VDC and 5 VDC power inputs

DCS Network Communication and Isolation Features

The Honeywell TC-CCR012 is designed for redundant network interface operation within Honeywell control architectures. The module provides network path coordination between redundant communication channels and maintains electrical interface functions between system components.

For Honeywell process control hardware environments, interface modules are typically integrated with distributed control system communication structures where signal integrity, channel separation, and controlled data exchange are required. The module architecture supports organized network connectivity and system-level redundancy management.

The TC-CCR012 is associated with Honeywell process control platforms where communication modules may interface with field control networks, controller backplanes, and I/O subsystems. Channel-to-channel isolation practices and proper grounding methods are required during installation to maintain communication stability.

Frequently Asked Questions

Q: What is the primary function of the Honeywell TC-CCR012 module?
A: The TC-CCR012 functions as a redundant network interface module, providing hardware-level communication interface capability for redundant network connections within Honeywell control systems.

Q: What are the specified power requirements of the TC-CCR012?
A: The module has a specified current draw of 1.000 A at 5 VDC and 0.002 A at 24 VDC.

Q: Does the available documentation specify operating temperature limits or hot-swap capability?
A: No operating temperature range or hot-swap limitation data is provided in the available technical information. Installation should follow the applicable Honeywell chassis and system hardware guidelines.

Field Installation Guidelines

• Install the TC-CCR012 in the designated Honeywell control system chassis position according to the system hardware configuration manual.
• Verify that the chassis power supply ratings support the module current requirements before energizing the system.
• Use appropriate industrial wiring practices for network connections, including separation from high-voltage power conductors and sources of electrical interference.
• Connect cable shields according to the system grounding design to reduce electromagnetic interference.
• Confirm connector seating and mechanical locking mechanisms before applying power.
• Verify redundant communication paths after installation through system diagnostic functions.
