Honeywell TC-CCN014 ControlNet Redundant Network Interface Module The Honeywell TC-CCN014, also cataloged as the TC-CCN014 ControlNet Redundant Network Interface Module,...
Read more
The Honeywell TC-CCN014, also cataloged as the TC-CCN014 ControlNet Redundant Network Interface Module, operates as a dedicated hardware component for redundant ControlNet communication management within Honeywell Experion PKS and C200 controller platforms.
Hardware Specifications
Parameter
Specification
Model
TC-CCN014
Brand
Honeywell
Origin
USA
Product Type
Redundant ControlNet Interface Modules
System Compatibility
Honeywell Experion PKS / C200 Controller Systems
Network Protocol
ControlNet
Interface Ports
Dual redundant ControlNet network ports
Input Voltage
24 VDC +/- 10%
Power Consumption
Approx. < 5 W
Node Addressing
Up to 99 nodes per network segment
Operating Temp
-40 deg C to +70 deg C
Storage Temp
-40 deg C to +85 deg C
Relative Humidity
0% to 95% non-condensing
Dimensions
Approx. 160 mm x 100 mm x 25 mm
Weight
Approx. 0.3 kg to 0.5 kg
Protection Rating
IP20
ControlNet Redundant Communication Architecture
The TC-CCN014 manages redundant ControlNet communication paths between Honeywell controller hardware and connected network devices. The dual-port configuration provides separated communication channels for network redundancy and fault isolation.
The module processes ControlNet data traffic through the Experion PKS and C200 controller architecture. Moreover, built-in diagnostic indicators provide status information for network activity, communication faults, and module operating conditions.
The communication interface is designed for industrial DCS installations where deterministic network timing and controlled data exchange are required. Therefore, installation configuration must follow Honeywell controller rack and ControlNet network design requirements.
Frequently Asked Questions
Q: Does the TC-CCN014 support redundant network operation?
A: Yes. The module provides dual ControlNet network interfaces for redundant communication path configuration and automatic network fault handling within supported Honeywell systems.
Q: What type of diagnostic information is available from the module?
A: The module provides LED-based status indication for communication activity, network conditions, and hardware operating states.
Q: Can the TC-CCN014 operate outside Honeywell Experion PKS and C200 architectures?
A: The module is designed for Honeywell control architectures. Compatibility should be verified against the specific controller chassis, firmware version, and ControlNet configuration.
Field Installation Guidelines
Install the module in the designated Honeywell controller rack position according to the system hardware manual.
Verify 24 VDC power wiring polarity before energizing the module.
Use approved ControlNet cabling and maintain proper shielding and grounding practices.
Separate communication cables from high-voltage power conductors to reduce electromagnetic interference.
Confirm network addressing and redundant communication settings before system commissioning.
Inspect connector seating and module locking mechanisms during installation and maintenance activities.
