Description
The Siemens 6DS1717-8CC is a specialized calculation module designed for the Teleperm M/ME industrial control systems. This PC board serves as a core component for binary processing tasks, providing reliable computational performance within established automation architectures.
Features
- Engineered specifically for Teleperm M/ME automation environments.
- Dedicated binary calculation functionality for process control logic.
- Compact PCB design for rack-based mounting.
- Integrated isolation for enhanced signal integrity and protection.
Technical Specifications
| Model |
6DS1717-8CC |
| Function |
Binary Calculation |
| Supply Voltage |
24 V DC (18–30 V range) |
| Current Consumption |
200 mA at 5 V |
| Isolation |
500 V AC module-to-earth |
| Operating Temperature |
0 degC to +60 degC |
| Storage Temperature |
-25 degC to +85 degC |
| Humidity |
5–95% RH (non-condensing) |
Installation Guidelines
- Ensure the control rack is powered down before inserting or removing the module to prevent electrical damage.
- Handle the PCB using ESD-safe practices to protect sensitive electronic components.
- Verify that the supply voltage is stable and within the 18–30 V DC range before energizing.
- Ensure adequate ventilation in the cabinet to maintain the required operating temperature range of 0 degC to +60 degC.
- Check that all backplane connections are fully seated to maintain proper ground and signal continuity.
FAQ
What is the primary function of the 6DS1717-8CC?
This module is a binary calculation board used within the Siemens Teleperm M/ME system to perform logic and arithmetic operations required for process automation.
Is this module compatible with other Siemens systems?
The 6DS1717-8CC is specifically designed for the Teleperm M/ME series. Compatibility with other Siemens platforms like SIMATIC S7 is not supported.
