The GE Fanuc IC610MDL152 is a high-density discrete output module engineered for the legacy Series One programmable logic controller (PLC) architecture. This module provides 16 independent digital output points, designed to operate at a rated voltage of 24 VDC. It is specifically utilized for driving intermediate relays, solenoids, and various indicator panels within automated control systems. By utilizing solid-state switching technology, the IC610MDL152 ensures reliable signal integrity and fast response times, helping to minimize system downtime in continuous industrial applications.
Features
- 16 independent digital output channels for high-density control.
- Rated for 24 VDC operation, compatible with standard industrial field actuators.
- Solid-state circuitry for enhanced reliability and reduced mechanical wear.
- Integrated D-connector interface for secure, high-density signal connectivity.
- Compact design optimized for efficient panel mounting within control cabinets.
Applications
The IC610MDL152 is widely deployed in legacy automation environments, including automotive assembly lines, water treatment facilities, and material handling systems where precise 24 VDC switching logic is required for field devices.
Technical Specifications
| Brand |
GE Fanuc |
| Model |
IC610MDL152 |
| Product Line |
Series One |
| Module Type |
Digital Output Module |
| Output Points |
16 |
| Rated Voltage |
24 VDC |
| Interface |
D Connector |
| Mounting |
Panel Mount |
| Operating Temperature |
0 to 40 deg C |
| Storage Temperature |
0 to 40 deg C |
| Relative Humidity |
Up to 80% (non-condensing) |
| Max Altitude |
1000 m |
Installation Guidelines
- Ensure all power is disconnected from the Series One rack before inserting or removing the module.
- Mount the module in a clean, dry, and vibration-dampened enclosure to maintain environmental ratings.
- Use appropriate shielded cabling for the D-connector interface to minimize electromagnetic interference (EMI).
- Verify that the 24 VDC power supply is properly regulated and grounded according to local electrical codes.
- Maintain adequate clearance around the module to allow for proper heat dissipation and airflow.
FAQ
Is this module compatible with modern GE Fanuc systems?
The IC610MDL152 is specifically designed for the legacy Series One PLC architecture. It is generally not compatible with modern GE Fanuc or Emerson PACSystems platforms without specialized migration hardware.
What type of connector is required for this module?
This module utilizes a D-connector interface. Ensure that your field wiring harness is compatible with the specific pinout of the IC610MDL152 to prevent signal errors or hardware damage.
