Description
Overview
The HMIGTO6310 Touch Screen from Schneider Electric delivers advanced visualization for industrial automation systems. It belongs to the Harmony GTO series and integrates seamlessly with PLC platforms using Modbus and Ethernet/IP protocols. This panel features a 12.1-inch TFT color display with 800×600 SVGA resolution and 65,536 colors. The HMIGTO6310 supports a 1024×1024 touch-sensitive zone, ensuring precise input even in demanding environments. Its compact housing measures 31.5×24.1×5.6cm and weighs 2.5kg, making it suitable for space-constrained control panels. The unit operates on a 24V DC supply (19.2–28.8V range) and handles up to 30A inrush current. The HMIGTO6310 includes 96MB Flash EPROM for program storage and 512KB internal RAM for data backup. A lithium battery maintains SRAM data for up to 100 days, supporting reliable data retention in critical applications. Designed for continuous use, the panel withstands temperatures from 0–55°C and humidity levels between 10–90% non-condensing. Its rugged build meets industrial standards for vibration and shock resistance.
Technical Specifications
| Specification |
Detail |
| Model Number |
HMIGTO6310 |
| Manufacturer |
Schneider Electric |
| System Type |
PLC |
| Product Range |
Harmony GTO Series |
| Display Size |
12.1-inch TFT |
| Resolution |
800 × 600 SVGA |
| Touch Zone |
1024 × 1024 |
| Dimensions |
31.5 × 24.1 × 5.6 cm |
| Weight |
2.5 kg |
| Input Voltage |
24V DC (19.2–28.8V) |
| Inrush Current |
30A |
| Flash Memory |
96MB EPROM |
| Internal RAM |
512KB |
| Battery Backup |
100 Days (Lithium) |
| Operating Temp |
0–55°C |
| Humidity Range |
10–90% Non-condensing |
| Protocols Supported |
Modbus, Ethernet/IP |
| Interface |
Ethernet Router |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
France |
| Discontinued Status |
Active |
Features & Benefits
-
HMIGTO6310 panel offers high-resolution display for real-time process visualization.
-
Large touch-sensitive zone ensures accurate input in industrial conditions.
-
Flash and RAM memory support complex automation programs and data retention.
-
Rugged housing resists vibration, shock, and environmental stress.
-
Compatible with Vijeo Designer software for streamlined application development.
