Description
Overview
The BMEP583040 Processor Module from Schneider Electric powers medium to large-scale automation systems. It belongs to the Modicon M580 PAC series and supports up to 8 rack configurations and 768 analog I/O channels. This compact module measures 3.1×9.7×10.2cm and weighs 0.16kg, making it ideal for dense control panel layouts. The BMEP583040 operates on 24V DC with a current draw of 295mA, ensuring stable performance in industrial environments. Schneider Electric equipped the BMEP583040 with Ethernet TCP/IP ports, HSBY communication, and a USB mini-B service port. It supports 16 remote I/O stations and 64 distributed devices, offering scalable architecture for complex systems. The module includes 12MB program RAM, 1024KB data memory, and expandable 4GB flash storage. It operates between 0°C and 60°C and stores safely from –40°C to 85°C. Its 600,000-hour MTBF and IP20 rating ensure long-term reliability.
Technical Specifications
| Specification |
Detail |
| Model Number |
BMEP583040 |
| Manufacturer |
Schneider Electric |
| System Type |
PLC |
| Product Range |
Modicon M580 Series |
| Dimensions |
3.1 × 9.7 × 10.2 cm |
| Weight |
0.16 kg |
| Operating Voltage |
24V DC |
| Current Consumption |
295 mA |
| Program RAM |
12MB |
| Data Memory |
1024KB |
| Flash Storage |
Expandable to 4GB |
| Remote I/O Support |
16 Stations |
| Distributed Devices |
64 Connections |
| Communication Ports |
Ethernet TCP/IP, USB mini-B, HSBY |
| MTBF Rating |
600,000 Hours |
| Operating Temp |
0°C to 60°C |
| Storage Temp |
–40°C to 85°C |
| Protection Rating |
IP20 |
| Certifications |
CE, UL, CSA |
| Compliance Standards |
EN 61131-2, EN 61000-6-4 |
| Interface |
Ethernet Router |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
France |
| Discontinued Status |
Active |
Features & Benefits
-
BMEP583040 supports 768 analog I/O channels for large-scale automation systems.
-
High memory capacity ensures fast processing and reliable data retention.
-
Multiple communication ports simplify integration with industrial networks.
-
Compact design and low power consumption improve installation flexibility.
-
Certified for global standards, ensuring safe and compliant operation.
