Description
Overview
The BMENOC0301 Ethernet Module from Schneider Electric enhances industrial communication for Modicon M580 PLC systems. It supports Ethernet/IP and Modbus TCP protocols, replacing the legacy 140NOM21200 module with advanced functionality. This compact module measures 5.1×10.2×10.2cm and weighs 0.2kg, offering a DIN-rail mountable design for efficient panel integration. The BMENOC0301 includes two RJ45 ports supporting 100Mbps and one X-bus rack port for seamless network expansion. Schneider Electric engineered the BMENOC0301 with RSTP protocol support, enabling robust ring topologies and network redundancy. An embedded web server allows real-time diagnostics and monitoring, improving system visibility and uptime. Powered internally via the main rack, the BMENOC0301 simplifies installation and reduces wiring complexity. Its IP20-rated enclosure and compliance with industrial standards ensure reliable performance in demanding environments.
Technical Specifications
| Specification |
Detail |
| Model Number |
BMENOC0301 |
| Manufacturer |
Schneider Electric |
| System Type |
PLC |
| Product Range |
Modicon M580 Series |
| Dimensions |
5.1 × 10.2 × 10.2 cm |
| Weight |
0.2 kg |
| Ethernet Ports |
2 × RJ45 (100Mbps), 1 × X-bus |
| Protocols Supported |
Ethernet/IP, Modbus TCP |
| Topology Support |
RSTP (Ring Network) |
| Web Server |
Embedded |
| Power Supply |
Internal via Rack |
| Mounting Type |
DIN Rail |
| Protection Rating |
IP20 |
| Compliance Standards |
IEC/EN Industrial Standards |
| Interface |
Ethernet Router |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
France |
| Discontinued Status |
Active |
Features & Benefits
-
BMENOC0301 supports 3 Ethernet ports for flexible industrial network architecture.
-
RSTP protocol enables fault-tolerant ring topologies across Ethernet networks.
-
Embedded web server provides real-time diagnostics and system monitoring.
-
Compact DIN-rail design simplifies installation and saves panel space.
-
Internal rack power supply reduces external wiring and setup time.
