The Schneider Electric ATV71H075N4Z is a high-performance variable speed drive designed for demanding industrial applications. As part of the Altivar 71 range, this unit provides precise motor control and energy efficiency for process and utility environments. This specific model is rated for 0.75 kW (1 HP) and operates within a 380-480V supply voltage range. This unit includes an integrated EMC filter for electromagnetic compatibility and is supplied without a graphic terminal.
Features
- Power rating: 0.75 kW / 1 HP.
- Supply voltage: 380-480V (-15% to +10%).
- Integrated EMC filter for noise reduction.
- Designed for complex process control and utility applications.
- Standard version configuration.
Technical Specifications
| Product Model |
ATV71H075N4Z |
| Manufacturer |
Schneider Electric |
| Product Type |
Variable Speed Drive |
| Power Rating |
0.75 kW / 1 HP |
| Supply Voltage |
380...480 V |
| Mains Voltage Tolerance |
10% |
| Network Frequency Tolerance |
5% |
| EMC Filter |
Integrated |
Installation Guidelines
- Ensure the drive is installed in a clean, dry, and well-ventilated environment to prevent overheating.
- Maintain adequate clearance around the drive as specified in the installation manual to allow for proper airflow.
- Verify that the supply voltage matches the drive's rated input range before connection.
- Use shielded cables for motor connections to minimize electromagnetic interference (EMI).
- Ensure proper grounding of the drive chassis to a common earth point to maintain safety and signal integrity.
- Always disconnect power and wait for the internal capacitors to discharge before performing any wiring or maintenance.
FAQ
Does this drive include a graphic display terminal? No, this specific part number (ATV71H075N4Z) is supplied without the graphic terminal.
What is the primary application for this drive? The Altivar 71 series is engineered for complex process and utility applications requiring high-performance motor control.
