Description
Overview
The ABE7H16R11 Interface Module from Schneider Electric supports passive discrete I/O integration for industrial automation. It fits seamlessly into PLC systems, offering reliable performance across manufacturing, energy, and building control applications. This module measures 24.2×12.6×10.5cm and weighs 1.18kg, making it suitable for compact control panels. The ABE7H16R11 operates on a 19–30V DC supply and conforms to IEC 61131-2 standards, ensuring stable performance in demanding environments. Equipped with 16 single-terminal channels, the ABE7H16R11 supports flexible and solid conductors up to 2.5mm². Each channel includes an LED indicator for real-time status, while a green LED confirms power readiness. The module features a 20-pin HE-10 connector for secure signal transmission and includes a 2A internal fuse for short-circuit protection. Its low voltage drop of 0.3V ensures efficient power delivery across connected devices. Mounting options include 35mm DIN rail or solid plate installation using a fixing kit. With 2000V insulation and IEC 60664-1 compliance, the ABE7H16R11 guarantees electrical safety and long-term durability.
Technical Specifications
| Specification |
Detail |
| Model Number |
ABE7H16R11 |
| Manufacturer |
Schneider Electric |
| System Type |
PLC |
| Product Range |
Schneider Electric |
| Dimensions |
24.2 × 12.6 × 10.5 cm |
| Weight |
1.18 kg |
| Channels |
16 Discrete Inputs |
| Voltage Range |
19–30V DC |
| Fuse Protection |
2A Internal Fuse |
| Connector Type |
20-pin HE-10 |
| Wire Size Support |
Up to 2.5 mm² |
| Voltage Drop |
0.3V |
| Max Current |
1.8A (0.5A per channel) |
| Insulation Voltage |
2000V |
| Mounting Options |
DIN Rail / Solid Plate |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
France |
| Discontinued Status |
Active |
Features & Benefits
-
ABE7H16R11 supports 16 channels with LED indicators for real-time monitoring.
-
Screw-type terminals accommodate flexible and solid wires up to 2.5mm².
-
2A fuse protection ensures safety for connected PLC systems.
-
HE-10 connector enables secure and efficient signal transmission.
-
Compact design and DIN rail mounting simplify panel integration.
