Description
Product Description
Overview
The Yokogawa S9562FA is an ESB Bus Node Unit designed to bridge field-level analog and contact I/O signals with a Field Control Unit (FCU). It provides reliable communication and power supply to connected I/O modules, ensuring stable operation across various industrial installations. The unit is compatible with standard 19-inch rack systems and supports multiple voltage configurations.
Key Features
-
Interface Function: Transfers analog and digital I/O data between field devices and FCU via ESB bus.
-
Power Supply: Provides stable power to I/O modules for consistent performance.
-
Connectivity: Establishes a secure communication link with the FCU through the ESB bus.
-
Versatile Voltage Options: Supports 100-120VAC, 220-240VAC, and 24VDC input for diverse installations.
-
Rack Compatibility: Designed for standard 19-inch rack mounting.
Technical Specifications
-
Model: S9562FA
-
Part/Order Number: Not specified
-
Module Type: Connector Unit / ESB Bus Node
-
Supported Power Sources: 100-120VAC, 220-240VAC, 24VDC
-
Power Consumption:
-
100-120VAC: 200VA, 120W
-
220-240VAC: 230VA, 120W
-
24VDC: 5.5A
-
Weight: 10 kg (with 8 I/O modules installed)
-
Mounting Type: 19-inch rack
-
Communication Protocol: ESB bus for analog and contact I/O
-
Operating Environment: Industrial temperature and humidity range
-
Dimensions: Standard 19-inch rack width, depth 250mm, height 132mm
-
Compliance: CE, RoHS
Applications
-
Field-to-FCU signal bridging in process control
-
Distributed I/O communication in industrial plants
-
Power and data management for modular I/O systems
-
Factory monitoring and process integration
FAQ
Q: How many I/O modules can the S9562FA support?
A: It supports up to 8 I/O modules per unit.
Q: Can it operate on both AC and DC power?
A: Yes, it supports 100-120VAC, 220-240VAC, and 24VDC input.
Q: Is it compatible with standard industrial racks?
A: Yes, it is designed for 19-inch rack installation.
Similar Model Comparison
-
S9561FA: Single I/O module support, smaller footprint
-
S9563FA: Supports 16 I/O modules, suitable for larger installations
