ABB PM866K02 Processor Unit Kit

Configured for redundant processor execution in ABB System 800xA control platforms, the ABB PM866K02 (PM866K02 Processor Unit Kit) provides direct hardware coordination between redundant CPU modules, CEX-Bus expansion, and RCU-Link communication components.

Hardware Specifications

Parameter	Specification
Model	PM866K02
Spare Model	3BSE050199R1
Brand	ABB
Product Type	Processor Unit Kit
Origin	Sweden
Weight	2.88 kg
Dimensions	27.5 x 21 x 13.5 cm estimated shipping size
Processor Configuration	Redundant processor unit configuration
Included Components	2 pcs PM866K01, TK850 CEX-Bus Expansion Cable, TK851 RCU-Link Cable

Industrial Control Network Integration

The PM866K02 uses ABB controller architecture for redundant processing tasks within System 800xA environments. Therefore, the kit integrates dual PM866K01 processor units with dedicated communication accessories to support synchronized controller operation.

The processor arrangement supports backplane bus communication and controller redundancy functions. Additionally, the included TK850 CEX-Bus expansion cable provides processor-to-expansion connectivity, while the TK851 RCU-Link cable supports redundant controller communication paths.

ABB processor platforms apply deterministic control communication methods for I/O density scaling and firmware flash compatibility management. These functions allow engineering teams to maintain consistent controller configuration across redundant processing assemblies.

Frequently Asked Questions

Q: What components are included in the PM866K02 processor unit kit?
A: The PM866K02 kit contains two PM866K01 processor units, one TK850 CEX-Bus expansion cable, and one TK851 RCU-Link cable. A software license is not included.

Q: Does the PM866K02 support redundant processor operation?
A: Yes. The PM866K02 is configured as a redundant processor unit kit based on two PM866K01 processor modules.

Q: Is the PM866K02 RoHS 2 compliant?
A: The provided technical information states that this part is not compliant with RoHS 2 2011/65/EU requirements.

Field Installation Guidelines

• Install the PM866K02 assembly inside the approved ABB controller cabinet or equipment enclosure.
• Verify correct mechanical mounting of processor modules before connecting CEX-Bus and RCU-Link cables.
• Route communication cables separately from high-voltage power wiring to reduce electromagnetic interference.
• Maintain proper cable shielding and grounding practices according to ABB installation requirements.
• Confirm processor redundancy configuration through the engineering tool before placing the controller system into operation.
• Inspect connectors and cable interfaces for contamination, mechanical damage, or improper seating before commissioning.

Specifications

• Brand: ABB

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
