Description
The Allen-Bradley 2711P-K12C15A1 is a high-performance PanelView Plus 1250 operator interface terminal designed for robust visual monitoring and real-time control in demanding industrial environments. Featuring a 12.1-inch active-matrix color TFT display and a tactile keypad, this unit provides reliable interaction for complex machinery in sectors such as power generation, chemical processing, and mining. The terminal utilizes the ControlNet communication protocol to ensure deterministic data exchange and seamless integration with Allen-Bradley programmable automation controllers.
Features
- 12.1-inch full-color TFT display for clear process visualization.
- Tactile keypad interface for reliable input in industrial settings.
- Integrated ControlNet communication port for high-speed, deterministic network connectivity.
- Internal 85-264 VAC power supply for versatile installation.
- 64 MB system memory for efficient runtime variable handling and alarm logging.
- Ruggedized enclosure designed for panel mounting in harsh environments.
Applications
This operator terminal is engineered for use in distributed control systems where high-speed, deterministic communication is required. It is suitable for monitoring and controlling automated processes in manufacturing, water treatment, and heavy industrial plants.
Technical Specifications
| Brand |
Allen-Bradley |
| Model |
2711P-K12C15A1 |
| Product Line |
PanelView Plus 1250 |
| Display Size |
12.1 in. |
| Display Type |
Full Color TFT |
| Input Type |
Keypad |
| Input Power |
85-264 VAC |
| Memory |
64 MB |
| Communication |
ControlNet |
| Operating Temperature |
0-55 deg C |
Installation Guidelines
- Ensure the panel cutout is prepared according to the manufacturer's specifications to maintain the integrity of the enclosure seal.
- Use appropriate mounting hardware to secure the terminal to the enclosure door, ensuring the gasket is correctly seated to prevent ingress of dust or moisture.
- Verify that the power supply voltage is within the 85-264 VAC range before connecting to the terminal.
- Maintain adequate clearance around the unit to allow for proper heat dissipation and airflow.
- Follow standard ESD precautions when handling the terminal to prevent damage to internal logic components.
- Ensure the ControlNet cable is routed away from high-voltage power lines to minimize electromagnetic interference.
FAQ
Is the 2711P-K12C15A1 still in production?
No, this model is classified as discontinued/obsolete. It is typically sourced as a spare part for existing legacy systems.
What type of communication does this HMI support?
This specific model is equipped with a ControlNet communication interface for deterministic fieldbus data exchange.
What is the required power source for this terminal?
The unit operates on an AC power supply ranging from 85 to 264 VAC.
