Overview
The 5X00501G01 (Ovation) Analog Input Module is engineered for the Emerson Ovation Distributed Control System (DCS). It ensures highly accurate signal acquisition for precise monitoring and control of industrial processes. Built for robustness and long-term reliability, this module performs consistently in demanding industrial environments.
Key Specifications
-
Manufacturer: Emerson
-
Model/Part Number: 5X00501G01
-
Product Type: Analog Input Module
-
Input Signal: 4–20 mA DC
-
Output Signal: 0–10 mV DC
-
Power Supply: 100–240 VAC, 50/60 Hz
-
Resolution: 12-bit
-
Accuracy: ±0.01% Full Scale
-
Sampling Rate: 100 µs per channel
-
Communication Interface: RS-485
-
Environmental Protection: IP20
-
Operating Temperature: -20°C to +60°C (-4°F to +140°F)
-
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
-
Dimensions: Height 178 mm × Width 73 mm × Depth 28 mm (7.0" × 2.9" × 1.1")
-
Weight: 0.25 kg (0.55 lbs)
-
Certifications: CE, UL, RoHS
Applications
The 5X00501G01 is suitable for precise analog signal acquisition in:
-
Power plant control and monitoring systems
-
Industrial process automation
-
Chemical and petrochemical instrumentation
-
Water and wastewater management systems
FAQ
Q: What input signals does this module support?
A: It accepts 4–20 mA DC signals.
Q: Is the module compatible with RS-485 communication networks?
A: Yes, it integrates seamlessly with RS-485 networks.
Q: What environmental conditions can it operate under?
A: Rated IP20, it functions reliably from -20°C to +60°C and can be stored safely down to -40°C.
Q: How does it compare to similar Ovation modules?
A: Compared to models like 5X00502G01, the 5X00501G01 provides the same input precision but has a more compact form factor, ideal for limited-space installations.
