Description
Product Description
The Honeywell TP-DIKBTA-100 (51196694-300) is a termination panel specifically designed for Series-C digital input modules within the Experion PKS system. It provides a secure interface between field wiring and DI modules, ensuring organized, reliable, and robust connections. Compact yet durable, this panel supports high-density wiring while simplifying installation and maintenance in industrial control environments.
Technical Specifications
| Specification |
Details |
| Supported Module |
Series-C Digital Input (DI) modules |
| Channels |
Supports 32 digital input channels via connected module |
| Input Voltage Range |
24 VDC typical |
| Connection Type |
Screw-type or compression terminals (version-dependent) |
| Isolation |
Channel-to-channel and channel-to-bus isolation supported |
| Diagnostics |
Supports module-level short/open detection |
| Operating Temperature |
-40°C to +70°C |
| Storage Temperature |
-40°C to +85°C |
| Relative Humidity |
5% to 95% non-condensing |
| Mounting Style |
Panel or chassis mounting |
| Dimensions |
Compact design for cabinet installation |
| Certifications |
CE, CSA, UL, ATEX compliant |
Key Features & Advantages
-
Secure Wiring Termination: Ensures reliable connections for digital input signals.
-
High Channel Density: Supports up to 32 DI channels per connected module.
-
Industrial-Grade Durability: Robust construction suitable for harsh environments.
-
Seamless Integration: Fully compatible with Experion PKS Series-C DI modules.
-
Simplified Maintenance: Organized wiring layout reduces troubleshooting and commissioning time.
Applications
-
Distributed control systems in refining, petrochemicals, and power generation
-
Chemical process plants and manufacturing operations
-
Any industrial environment requiring high-density digital input wiring
-
Control systems where reliable DI termination is critical
FAQ
Q: Can TP-DIKBTA-100 be used without a connected DI module?
A: No, the panel requires a compatible Series-C DI module to process input signals.
Q: How many channels does the panel support?
A: Up to 32 digital input channels per connected DI module.
Q: Is it compatible with non-Honeywell systems?
A: It is specifically designed for Honeywell Experion PKS Series-C; functionality may be limited outside this ecosystem.
Q: Are there similar termination panels in the Series-C family?
A: Yes, other TP assemblies like TP-DIKBTA-101 or TP-DIKBTA-102 support different DI module configurations or higher channel counts.
