Honeywell TK-PRS021 Control Processor Module

Configured for control execution and processing tasks in the Honeywell Experion PKS C200 system, the Honeywell TK-PRS021 51404305-275 (TK-PRS021 Control Processor Module) provides direct processor-level control functions for C200 controller architectures.

Hardware Specifications

Parameter	Specification
Model	TK-PRS021 51404305-275
Brand	Honeywell
Product Type	Control Processor Module
System Platform	Experion PKS C200
Function	Control processor execution module
Power Supply	24 VDC
Conformal Coating	Yes
Origin	USA
Weight	0.4 kg
Dimensions	7 x 14 x 14.5 cm (shipping size)
Operating Temp	Not specified
Power Consumption	Not specified
Tariff Code	8537101190
Spare Model	51404305-275

Process Control Interface and DCS Module Characteristics

The TK-PRS021 is designed for Honeywell Experion PKS C200 controller assemblies and performs processor-level execution of configured control strategies. The module interfaces with the C200 controller backplane for internal communication and coordinated processing of controller functions.

For Honeywell process control architectures, module-level design considerations include channel-to-channel isolation practices, analog signal integrity management, and compatibility with field communication standards such as 4-20 mA HART loop protocol and FOUNDATION Fieldbus / Profibus PA connectivity when implemented through associated I/O interfaces.

The conformal coating specification provides additional protection for electronic assemblies against environmental contaminants encountered in industrial control cabinets. Installation should maintain proper cabinet grounding, shielding, and airflow conditions according to the Experion PKS hardware configuration requirements.

Frequently Asked Questions

Q: Is the TK-PRS021 configured as an independent standalone controller?
A: No. The TK-PRS021 is a Control Processor Module intended for installation within the Honeywell Experion PKS C200 controller architecture and operates as part of the controller assembly.

Q: Does the TK-PRS021 support direct field wiring connections?
A: No. The module performs processor functions and communicates through the controller backplane. Field signal connections are handled through compatible I/O modules.

Q: What installation considerations apply to the conformal coated version?
A: The module should be installed in a compatible chassis with correct backplane engagement, proper grounding, and controlled cabinet environmental conditions. Specific operating limits should follow Honeywell Experion PKS installation documentation.

Field Installation Guidelines

• Install the TK-PRS021 only in the designated Honeywell C200 controller chassis position.
• Verify backplane connector alignment before insertion to prevent mechanical damage.
• Confirm cabinet grounding continuity before connecting the controller assembly.
• Maintain separation between signal wiring, power wiring, and high-noise electrical sources.
• Use appropriate cable shielding and grounding methods for connected process control networks.
• Follow Honeywell Experion PKS engineering documentation for firmware compatibility and controller configuration procedures.
