Honeywell TK-PRR021 51309288-275 Redundancy Module Configured for controller redundancy synchronization in Honeywell Experion PKS control network architectures, the Honeywell TK-PRR021...
Read more
SKU: TK-PRR021 51309288-275
Country of origin: USA
Configured for controller redundancy synchronization in Honeywell Experion PKS control network architectures, the Honeywell TK-PRR021 51309288-275 (TK-PRR021 Redundancy Module) provides direct physical and electrical execution for redundant module communication and power distribution functions.
Hardware Specifications
Parameter
Specification
Model
TK-PRR021 51309288-275
Brand
Honeywell
Product Type
Redundancy Module
Origin
USA
Weight
0.46 kg
Dimensions
6.9 x 14.1 x 14.5 cm
Operating Temp
-20 deg C to +70 deg C
Storage Temperature
-40 deg C to +85 deg C
Relative Humidity
5-95% non-condensing
Power Supply
24 VDC +/-10%
Power Consumption
5 W typical, 8 W maximum
Sync Speed
100 Mbps full duplex
Isolation
1500 V AC
Electrical Range
0.75-1 A / 7-90 mA / 3.3-24 VDC
Process Control Communication and Isolation Characteristics
The Honeywell TK-PRR021 provides redundancy communication between compatible control modules through a full duplex 100 Mbps synchronization interface. The module supports controlled data exchange between redundant hardware paths while maintaining electrical separation through 1500 V AC isolation.
The module design follows Honeywell process control hardware requirements for distributed control environments. Furthermore, the isolation structure supports channel-to-channel separation principles used in industrial I/O and controller interconnection systems.
For process instrumentation integration, Honeywell control platforms typically use standardized signal interfaces such as 4-20 mA HART loop protocol and FOUNDATION Fieldbus / Profibus PA connectivity. The TK-PRR021 itself functions as a redundancy communication component rather than an analog signal acquisition module.
Frequently Asked Questions
Q: What is the primary function of the Honeywell TK-PRR021 module? A: The TK-PRR021 is a redundancy module designed to manage synchronization and electrical connection functions between redundant control hardware components.
Q: What power input does the TK-PRR021 require? A: The module requires a 24 VDC power supply with an operating tolerance of +/-10%. Power consumption is 5 W typical and 8 W maximum.
Q: Does the TK-PRR021 provide electrical isolation? A: Yes. The module provides 1500 V AC isolation between relevant electrical sections to support separation requirements in industrial control installations.
Field Installation Guidelines
Install the TK-PRR021 in the designated Honeywell control hardware chassis according to the system configuration documentation.
Verify that the 24 VDC power source meets the specified voltage range before connection. Use appropriate grounding practices and maintain separation between power wiring and communication wiring to reduce electrical interference.
Ensure communication cables follow industrial installation requirements for routing, shielding, and termination. Avoid installing the module in locations exceeding the specified operating temperature or humidity limits.
Before system startup, confirm redundancy configuration parameters, module status indicators, and synchronization communication conditions within the controller engineering environment.
