Description
Overview
The Honeywell TC-ODD321 Experion DC Output Module delivers 32 discrete outputs at 24 VDC, ensuring efficient control in automation systems. Honeywell designed this module with compact dimensions and robust protection, making it ideal for demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
TC-ODD321 |
| Manufacturer |
Honeywell |
| Module Type |
Experion DC Output Module |
| Output Channels |
32 points, grouped 16 per common |
| Input Voltage Range |
10–31.2 VDC |
| Output Current |
100 mA per channel |
| Isolation |
250 VAC opto-isolated |
| Power Supply |
24 VDC |
| Dimensions |
3.5 × 14 × 14.5 cm |
| Weight |
0.24 kg |
| Protection Rating |
IP65 |
| Mounting |
DIN rail |
| HS Code |
8537101190 |
| Origin |
USA |
| System |
DCS |
| Communication Service |
Ethernet router |
Design and Build
Honeywell engineered the TC-ODD321 with IP65 protection, ensuring resistance against dust and moisture. Its DIN rail mounting design simplifies installation while maintaining durability in harsh industrial conditions.
Performance
The TC-ODD321 supports 32 opto-isolated channels, each capable of delivering 100 mA. It maintains stable operation across a wide voltage range and includes configurable fault states such as Hold Last State, ON, or OFF.
Applications and Compatibility
The Honeywell TC-ODD321 integrates seamlessly with Experion PKS and broader Honeywell DCS systems. Industries use this module for factory automation, process control, and machinery operation. Its high-density outputs and rugged design make it suitable for complex automation tasks requiring reliability and adaptability.
