Description
Product Overview
The Honeywell TC-IOLI01 Input Module captures discrete field signals for Honeywell DCS architectures. The compact 7×14×14.5 cm size and 0.4 kg weight support efficient installation in automation cabinets. The module handles both 120 VAC and 24 VDC inputs, giving engineers flexibility when integrating mixed‑voltage field devices.
Technical Specifications
| Parameter |
Specification |
| Model Number |
TC-IOLI01 |
| Category |
Digital Input Module |
| Manufacturer |
Honeywell |
| System |
DCS / Honeywell Platforms |
| Input Types |
120 VAC (50/60 Hz) / 24 VDC |
| Current Consumption |
13 mA per Point |
| Compatible Cable Assemblies |
1492‑HWCAB / 1492‑HWACAB |
| Compatible RTP Models |
1492‑AIFM / 1492‑RIFM |
| Expansion Support |
XIM Relay Interface Modules |
| Weight |
0.4 kg |
| Dimensions |
7 × 14 × 14.5 cm |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| MOQ |
1 |
Design & Performance
The Honeywell TC-IOLI01 processes digital inputs with stable performance across industrial environments. The module supports 13 mA per point, ensuring consistent signal acquisition from switches, sensors, and contact devices. Honeywell designs the TC-IOLI01 to integrate smoothly with pre‑wired cable assemblies that simplify wiring and reduce installation time.
Electrical & Mechanical Characteristics
The Honeywell TC-IOLI01 works with both AC and DC signals, enabling flexible deployment across diverse field applications. The module supports Remote Terminal Panels that streamline wiring and maintenance. Its rugged construction ensures stable operation in demanding industrial conditions.
Installation & Integration
Technicians integrate the Honeywell TC-IOLI01 easily due to its compatibility with Honeywell RTPs and cable assemblies. The module supports scalable architectures that may include relay interface modules for higher‑current applications. Its compact footprint improves cabinet density and supports clean wiring layouts.
Applications & Compatibility
The Honeywell TC-IOLI01 supports a wide range of automation tasks, including:
-
Discrete signal acquisition in DCS networks
-
Machine automation and equipment monitoring
-
Process control and valve feedback systems
-
Building automation and security detection
-
Mixed‑voltage digital input integration
Its strong interoperability and modular design make the TC-IOLI01 a dependable choice for modern industrial control systems.
