Description
Overview
The Honeywell TC-FXX172 Slot Rack Chassis provides a robust backbone for industrial automation systems. Honeywell designed this 17-slot chassis to deliver stable 24VDC at 2.8A, ensuring reliable integration of I/O, communication, and processing modules.
Technical Specifications
| Parameter |
Value |
| Model Number |
TC-FXX172 |
| Manufacturer |
Honeywell |
| Module Type |
Slot Rack Chassis |
| Slots Available |
17 |
| Output Voltage / Current |
24 VDC / 2.8A |
| Dimensions |
17.1 × 40.0 × 14.6 cm |
| Weight |
1.4 kg |
| HS Code |
8537101190 |
| Origin |
USA |
| System |
DCS / Experion PKS |
| Communication Service |
Ethernet router |
| MOQ |
1 |
Design and Build
Honeywell engineered the TC-FXX172 with an uncoated design that prioritizes efficient heat dissipation and electrical performance. Its scalable architecture supports flexible arrangement of controllers and I/O cards, making it suitable for complex automation systems.
Performance
The TC-FXX172 delivers consistent 24VDC output at 2.8A, ensuring stable operation across demanding environments. Its 17-slot capacity allows engineers to expand system functionality while maintaining reliable data exchange and seamless process integration.
Applications and Compatibility
The Honeywell TC-FXX172 integrates with Experion PKS and legacy TDC3000 systems. Industries deploy this chassis for loop regulation, logic control, advanced optimization, and safety applications. Its scalable design supports both basic regulatory functions and complex distributed control strategies, making it a versatile choice for modern automation infrastructure.
