Description
Overview
The Honeywell TC-1AH161 High Level Analog Input Module delivers precise signal acquisition for demanding automation environments. Engineers rely on its 16-channel design, ±0.2% accuracy, and IP67-rated housing to ensure reliable performance in complex industrial systems.
Technical Specifications
| Parameter |
Details |
| Model Number |
TC-1AH161 |
| Manufacturer |
Honeywell |
| Module Type |
High Level Analog Input Module |
| Dimensions |
8.8 × 22.5 × 17.5 cm |
| Weight |
1.26 kg |
| HS Code |
8537101190 |
| Channels |
16 high-level inputs |
| Signal Range |
0–10 VDC, 0–20 mA |
| Accuracy |
±0.2% ±2 LSB |
| Power Supply |
24 VDC, max 10 mA |
| Operating Temperature |
-40°C to +85°C |
| Housing Protection |
IP67 dust and moisture resistant |
| System Compatibility |
DCS |
| Condition |
Brand New |
| Origin |
USA |
| MOQ |
1 |
| Communication Service |
Ethernet router |
| Discontinued On |
Active |
Functional Highlights
Honeywell designed the TC-1AH161 to support both voltage and current signals, making it versatile for multi-sensor systems. Its compact 8.8 × 22.5 × 17.5 cm design and 1.26 kg weight allow flexible installation in space-constrained environments.
The TC-1AH161 operates efficiently on a 24 VDC supply with minimal energy consumption. Its IP67-rated housing ensures protection against dust and moisture, while four internal sensors provide accurate monitoring across extreme temperatures.
Applications and Compatibility
The Honeywell TC-1AH161 suits industries requiring precise analog input modules, including manufacturing automation, energy systems, and process control. Engineers deploy this module to enhance system integration, improve monitoring accuracy, and maintain operational reliability. Its high channel density and robust construction make it a trusted solution for modern industrial automation setups.
