Description
Overview
The Honeywell SPU65-302 is a compact, industrial-grade AC/DC switching power supply engineered for automation, process control, and Honeywell DCS systems. It provides stable DC output from universal AC input, delivering 65–80W continuous power. Designed for rugged environments, this module is splash-proof, lightweight, and globally compatible.
Key Features
-
Wide Input Compatibility: Accepts 90–264 VAC, 47–63 Hz, suitable for worldwide operation
-
Flexible Output Configurations: Supports single to quad DC outputs ranging from 3 VDC to 48 VDC
-
Reliable Industrial Operation: Splash-proof design and 100% burn-in tested for durability
-
Safety Certified: Complies with UL, C-UL, TUV, CE, FCC Part-15 Class B, and CISPR-22 Class B
-
Compact and Lightweight: Easy integration into Honeywell control systems or other industrial setups
-
Overload & Surge Protection: Safeguards connected devices against electrical faults
Technical Specifications
| Specification |
Details |
| Model |
Honeywell SPU65-302 |
| Type |
Industrial AC/DC Switching Power Supply |
| Input Voltage Range |
90–264 VAC, 47–63 Hz |
| Input Connector |
IEC-320-C14 |
| Output Voltage Range |
3–48 VDC |
| Output Configuration |
Single to Quad outputs |
| Output Ratings |
+5V: up to 6A; +12V: up to 2.125A; -12V: up to 0.325A |
| Power Capacity |
65–80W continuous |
| Protection Features |
Input surge, over-voltage, overload protection |
| Safety Compliance |
UL, C-UL, TUV, CE; FCC Part-15 Class B; CISPR-22 Class B |
| Design Features |
Splash-proof, 100% burn-in tested |
| Weight |
800 g |
Applications
-
Powering Honeywell DCS modules and peripheral devices
-
Industrial automation, process control, and IT equipment
-
Compact installations requiring multiple DC voltage outputs
-
Replacement or upgrade for legacy industrial power supplies
FAQ
Q: What output voltages does this module provide?
A: The SPU65-302 offers outputs ranging from 3 VDC to 48 VDC, supporting single to quad configurations.
Q: Can it operate worldwide?
A: Yes, it accepts a universal AC input of 90–264 VAC, 47–63 Hz.
Q: Is this power supply safe for continuous industrial operation?
A: It is splash-proof, burn-in tested, and certified to multiple safety standards for reliable continuous use.
Q: What industries is it commonly used in?
A: Typical applications include automation, process control, manufacturing, and Honeywell DCS environments.
