The Honeywell RM7850A1019 is a microprocessor-based burner management relay module designed for the 7800 SERIES control system. It provides reliable, programmable combustion sequencing for single-burner industrial applications, including gas, oil, and dual-fuel boilers. The module is engineered to manage critical safety functions such as interrupted pilot ignition, second-stage pilot valve control, and post-purge sequencing, ensuring safe and efficient burner operation in power plants, refineries, and process heating environments.
Features
- Programmable burner management for single-burner firing systems.
- Supports user-selectable airflow check functions for enhanced safety.
- Executes precise pre-ignition sequencing and intermittent second-stage pilot valve control.
- Integrated 15-second post-purge cycle to ensure combustion chamber clearance.
- Continuous monitoring of lockout interlocks with deterministic fault handling.
- Designed for seamless integration with the Honeywell 7800 SERIES backplane architecture.
Applications
The RM7850A1019 is widely utilized in industrial combustion control environments, including:
- Industrial and commercial boiler management systems.
- Refinery process heating units.
- Power generation combustion control.
- Staged combustion systems requiring intermittent pilot control.
Technical Specifications
| Model |
RM7850A1019 |
| Series |
7800 SERIES |
| Power Supply |
120 VAC, 50/60 Hz |
| Power Consumption |
< 10 W |
| Operating Temperature |
0 to 60 deg C |
| Pilot Configuration |
Interrupted pilot with intermittent second-stage pilot |
| Post Purge Duration |
15 seconds |
Installation Guidelines
- Ensure power is disconnected before installing or removing the module from the 7800 SERIES backplane.
- The module must be installed in a clean, dry environment protected from excessive vibration and moisture.
- Verify that all wiring connections to the backplane are secure and conform to local electrical codes.
- Use anti-static precautions when handling the module to prevent damage to internal circuitry.
- Ensure proper grounding of the control cabinet to minimize EMI/RFI interference.
- Regularly inspect the flame detection components and purge timers for optimal system performance.
FAQ
What is the primary function of the RM7850A1019?
This module acts as a primary burner control relay, managing the ignition sequence, pilot valve control, and safety interlocks for single-burner combustion systems.
Does this module support post-purge?
Yes, the RM7850A1019 includes a fixed 15-second post-purge cycle to clear the combustion chamber of residual gases after a shutdown.
Is this module compatible with other 7800 SERIES components?
Yes, it is designed to interface directly with 7800 SERIES backplanes, display modules, and flame detection sensors.
