Honeywell MU-KGPR05 Control Cable Assembly

Configured for signal interconnection between control modules and termination assemblies in Honeywell TDC 3000 and Experion PKS systems, the Honeywell MU-KGPR05 (51109620-195) MU-KGPR05 Control Cable Assembly provides direct physical signal routing between system hardware interfaces.

Hardware Specifications

Parameter	Specification
Model	MU-KGPR05
Brand	Honeywell
Origin	Germany or Honeywell certified manufacturing facility
Operating Temp	-20 deg C to +75 deg C typical industrial range
Power Consumption	Passive cable assembly, no external power consumption
Part Number	51109620-195
Component Type	Control Cable Assembly / Interconnect Cable
Application	TDC 3000 and Experion PKS DCS I/O interconnection
Signal Interface	Control signal and module-level electrical connection
Shielding	Industrial shielded construction for EMI and RFI reduction
Connector Type	Dedicated Honeywell multi-pin industrial connectors
Cable Construction	Industrial-grade conductors with protective jacket and shielding layer

Honeywell DCS Signal Interconnection Characteristics

The MU-KGPR05 is designed for physical signal transmission between Honeywell control hardware assemblies. It maintains electrical continuity between I/O modules, termination assemblies, and related control system interfaces.

For Honeywell process control architectures, cable assemblies support field signal routing requirements associated with DCS hardware. Therefore, proper cable selection and installation maintain signal integrity for connected analog and digital channels.

The cable assembly design supports industrial wiring practices, including controlled routing, shield management, and separation from high-voltage conductors. In addition, proper grounding of the shielding layer reduces electromagnetic interference during system operation.

Frequently Asked Questions

Q: Does the Honeywell MU-KGPR05 require an external power supply?
A: No. The MU-KGPR05 is a passive cable assembly and does not consume external electrical power.

Q: Can the MU-KGPR05 be installed without considering cable shielding?
A: No. The shield layer should follow the Honeywell system grounding practice to reduce electromagnetic interference and maintain signal quality.

Q: Is the MU-KGPR05 compatible with non-Honeywell termination systems?
A: The cable assembly uses dedicated Honeywell connection interfaces. Compatibility depends on the installed control hardware and connector configuration.

Field Installation Guidelines

• Verify the MU-KGPR05 part number before installation to confirm compatibility with the target Honeywell control assembly.
• Install the cable according to the system wiring documentation and connector pin assignment requirements.
• Keep the cable separated from power cables, motor feeders, and high-noise electrical sources.
• Maintain proper shield termination according to the Honeywell DCS grounding specification.
• Avoid excessive bending, mechanical stress, or connector loading during cable routing.
• Inspect connector contacts before installation to prevent signal interruption caused by contamination or improper engagement.

Specifications

• Brand: Honeywell

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
