The Honeywell MU-GAIH13 is a high-level analog input (HLAI) smart transmitter interface (STI) field termination assembly (FTA). It is engineered for integration within Honeywell TPS and process automation systems to facilitate the acquisition of analog signals from field instrumentation. This module supports up to 16 high-level DC analog channels, providing isolated floating DC power for 2-wire or 3-wire 4-20 mA transmitters, particularly in hazardous process environments. The unit functions by repeating the transmitter current into a safe-area range spool circuit, which produces a 1 to 5 VDC signal compatible with Honeywell HLAI IOP modules.
Features
- Supports 16 independent analog input channels.
- Provides isolated floating DC power for field-mounted transmitters.
- Compatible with both 2-wire and 3-wire 4-20 mA smart transmitter configurations.
- Converts field current inputs to 1-5 VDC output signals for DCS processing.
- Designed for high-reliability signal conditioning in electrically noisy environments.
- Reduces signal distortion and enhances transmitter stability.
Applications
The MU-GAIH13 is widely utilized in critical process industries, including:
- Refinery and petrochemical processing units.
- Offshore oil and gas production platforms.
- Thermal and nuclear power generation facilities.
- Hazardous-area process automation and control systems.
Technical Specifications
| Model |
MU-GAIH13 |
| Channel Capacity |
16 Analog Input Channels |
| Input Signal |
4-20 mA DC |
| Output Signal |
1-5 VDC |
| Transmitter Support |
2-wire and 3-wire Smart Transmitters |
| System Compatibility |
Honeywell TPS DCS |
| Operating Temperature |
0 to 60 deg C |
| Storage Temperature |
-40 to 85 deg C |
| Humidity |
5 to 95% non-condensing |
| Power Consumption |
Approx. 8 W |
Installation Guidelines
- Ensure the cabinet mounting surface is clean and provides adequate grounding for the FTA assembly.
- Always power down the system before installing or removing the module to prevent electrical damage.
- Use shielded twisted-pair cabling for all analog signal runs to minimize EMI/RFI interference.
- Maintain proper segregation between signal wiring and high-voltage power lines within the cabinet.
- Verify that the floating power supply configuration matches the specific requirements of the connected field transmitters.
- Handle with standard ESD precautions to protect internal circuitry.
FAQ
What is the primary function of the MU-GAIH13?
The MU-GAIH13 serves as an interface between field-mounted 4-20 mA transmitters and the Honeywell DCS. It provides the necessary power to the transmitters and converts the current signal into a 1-5 VDC voltage signal that the control system can process.
Is this module suitable for hazardous locations?
Yes, the MU-GAIH13 is designed to provide the necessary isolation for transmitters installed in hazardous process environments, ensuring safe operation within the broader Honeywell TPS architecture.
