Description
Overview
The MLI-DR40SU Honeywell Base Module is a high-density relay output unit designed for the MasterLogic-50 PLC series. With 40 relay outputs capable of switching up to 2A at 220 VAC or 24 VDC, it provides robust load-handling capabilities for motors, solenoids, actuators, and other industrial devices. Built to IEC international standards, the module ensures safe, reliable operation in demanding automation environments.
Technical Specifications
| Parameter |
Specification |
| Model Number |
MLI-DR40SU |
| Product Type |
Base Module |
| Brand |
Honeywell |
| Condition |
New |
| Product Range |
MasterLogic-50 PLC |
| Output Channels |
40 relay outputs |
| Switching Capacity |
2A at 220 VAC / 24 VDC |
| Supported Loads |
Resistive, inductive, and lamp loads |
| Operating Temperature |
0–55 °C |
| Isolation |
IEC-compliant electrical safety features |
| Communication |
Supports multiple industrial protocols |
| Diagnostic Features |
LED indicators and built-in troubleshooting functions |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
0.4 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| MOQ |
1 |
| Availability |
In Stock |
Key Features
-
40-point relay output design for extensive load control
-
High switching capacity for diverse industrial applications
-
Compact form factor for efficient panel integration
-
Wide operating temperature range for durability in harsh conditions
-
Diagnostic indicators for simplified maintenance and troubleshooting
-
Seamless integration with other MasterLogic-50 modules
Application Scenarios
-
Manufacturing plants requiring large-scale relay output capacity
-
Energy management systems with extensive load switching needs
-
Process industries needing reliable control of motors and actuators
-
Automation environments requiring IEC-compliant safety and performance
FAQ
Q: What loads can the MLI-DR40SU handle? A: It supports resistive, inductive, and lamp loads up to 2A per channel.
Q: Is the module suitable for high-density applications? A: Yes, with 40 relay outputs, it is ideal for systems requiring extensive switching capacity.
Q: How does this module integrate with other Honeywell components? A: It is fully compatible with MasterLogic-50 PLC modules, supporting expandable configurations.
Q: How does it compare to smaller Honeywell base modules? A: The MLI-DR40SU offers higher output density and switching capacity, while models like MLI-DN14E are designed for entry-level applications with fewer I/O points.
