Description
Overview
The MLI-DR32H/D1 Honeywell Power Supply Module is a high-performance relay output unit designed for integration into the MasterLogic-50 PLC series. Featuring 16 relay outputs and 16 digital inputs, it provides flexible control for a wide range of industrial automation applications. Its rugged design, fast processing speed, and long mechanical lifespan make it a reliable solution for demanding environments.
Technical Specifications
| Parameter |
Specification |
| Model Number |
MLI-DR32H/D1 |
| Product Type |
Power Supply Module |
| Brand |
Honeywell |
| Condition |
New |
| Product Range |
MasterLogic-50 PLC |
| System Compatibility |
DCS |
| Digital Inputs |
16 channels, DC 12/24V |
| Relay Outputs |
16 channels, 2A at DC24V or AC220V |
| Output Grouping |
4 points per COM |
| Mechanical Lifespan |
>20 million operations |
| Processing Speed |
83 ns per instruction step |
| Expansion Capacity |
Up to 384 I/O points with additional modules |
| Isolation |
Relay insulation for safe operation |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
0.4 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| MOQ |
1 |
| Availability |
In Stock |
Key Features
-
16 relay outputs with high switching capacity for diverse load types
-
Supports resistive, inductive, and lamp loads up to 2A per channel
-
Compact design with efficient COM grouping for simplified wiring
-
Long mechanical lifespan exceeding 20 million operations
-
High-speed instruction execution for precise control
-
Scalable architecture supporting up to 384 I/O points
Application Scenarios
-
Manufacturing plants requiring reliable relay-based control of motors and solenoids
-
Energy management systems with high-density output requirements
-
Process industries needing robust and safe relay switching
-
Automation environments requiring compact modules with scalable expansion
FAQ
Q: What loads can the MLI-DR32H/D1 control? A: It supports resistive, inductive, and lamp loads up to 2A at DC24V or AC220V.
Q: How is wiring organized? A: Outputs are grouped into sets of 4 points per COM for simplified installation.
Q: What is the mechanical lifespan of the relays? A: The relays are rated for over 20 million operations, ensuring long-term reliability.
Q: How does it compare to the Honeywell MLI-DR40SU? A: The MLI-DR32H/D1 offers 16 relay outputs with compact grouping, while the MLI-DR40SU provides 40 relay outputs for higher-density applications.
