Description
Overview
The MLI-DP60SU Honeywell Base Module is a high-density digital I/O unit designed for the MasterLogic-50 PLC series. It combines 36 DC24V input channels with 24 relay outputs, providing versatile connectivity and precise control for complex automation tasks. With wide AC power compatibility and advanced processing speed, this module ensures reliable performance in demanding industrial environments.
Technical Specifications
| Parameter |
Specification |
| Model Number |
MLI-DP60SU |
| Product Type |
Base Module |
| Brand |
Honeywell |
| Condition |
New |
| Product Range |
MasterLogic-50 PLC |
| System Compatibility |
DCS |
| Input Channels |
36 × DC24V |
| Output Channels |
24 × relay outputs |
| Power Supply |
AC 100–240V |
| Rated Input Voltage/Current |
DC24V / 4 mA |
| Operating Voltage Range |
DC20.4–28.8V |
| Processing Speed |
94 ns per instruction step |
| Memory |
200 kB (≈15k steps), supports up to 128 programs |
| Control Modes |
Cyclic, interrupt, constant scan, direct instruction mode |
| Isolation |
Photo-coupler insulation, withstands AC560 Vrms for 3 cycles |
| Input Resistance |
5.6 kΩ (2 kΩ for specific channels) |
| Common Method |
12-point grouping |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
1.3 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| MOQ |
1 |
| Availability |
In Stock |
Key Features
-
36 DC inputs and 24 relay outputs for versatile control
-
High-speed processing at 94 ns per step
-
Supports multiple scan modes for flexible programming
-
Reliable insulation and surge protection for industrial environments
-
Compact design with efficient common grouping for wiring
-
Scalable memory supporting up to 128 programs
Application Scenarios
-
Manufacturing plants requiring high-density input/output modules
-
Energy facilities with complex monitoring and control needs
-
Chemical and petrochemical industries needing robust relay switching
-
Utility systems requiring scalable PLC integration
FAQ
Q: How many I/O channels does the MLI-DP60SU provide? A: It offers 36 DC24V inputs and 24 relay outputs.
Q: What is the processing speed of this module? A: Basic instructions are executed in 94 nanoseconds per step.
Q: How does it ensure electrical safety? A: Through photo-coupler insulation and AC560 Vrms withstand capability.
Q: How does it compare to the Honeywell MLI-DN32U/DC? A: The MLI-DP60SU provides higher I/O density with relay outputs, while the MLI-DN32U/DC includes analog I/O for mixed-signal applications.
