Description
Overview
The Honeywell MLF-DC04A Analog Output Module delivers precise current output for MasterLogic-50 PLC systems. Engineers integrate this 4-channel unit to control sensors, actuators, and industrial devices. Its compact 7×14×14.5 cm size and 0.5 kg weight simplify installation while ensuring robust performance in demanding environments.
Technical Specifications
| Parameter |
Specification |
| Model Number |
MLF-DC04A |
| Manufacturer |
Honeywell |
| Module Type |
Analog Output Module |
| System Compatibility |
MasterLogic-50 PLC, DCS |
| Channels |
4 analog output channels |
| Output Ranges |
4–20 mA, 0–20 mA |
| Data Formats |
Unsigned (0–4000), Signed (-2000–2000), Precise (200–2000 or 0–2000), Percentile (0–1000) |
| Resolution |
1/4000 (5 µA) |
| Accuracy |
±0.5% or less |
| Conversion Speed |
1.0 ms per channel |
| Max Absolute Input |
DC ±25 mA |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
0.5 kg |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| MOQ |
1 |
| Communication Service |
Ethernet router |
Functional Highlights
The Honeywell MLF-DC04A ensures rapid response with a conversion speed of 1.0 ms per channel. Its high resolution of 1/4000 and ±0.5% accuracy provide fine control for sensitive applications. Engineers configure analog ranges through Softmaster I/O settings, enabling flexible adaptation to different system requirements.
Applications and Compatibility
The Honeywell MLF-DC04A supports industries requiring precise current output, including manufacturing, energy, and process automation. Its robust design protects connected devices while enhancing MasterLogic PLC functionality. Engineers rely on this module for process control, monitoring, and automation tasks where accuracy and speed are critical.
