Description
Overview
The Honeywell MLE-TP32A Digital Output Module delivers precise control for automation systems with 32 independent transistor output channels. Engineers rely on its compact design, fast switching speed, and robust construction to ensure reliable performance in demanding industrial environments.
Technical Specifications
| Parameter |
Details |
| Model Number |
MLE-TP32A |
| Manufacturer |
Honeywell |
| Module Type |
Digital Output Module |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
0.4 kg |
| HS Code |
8537101190 |
| Channels |
32 |
| Operating Voltage |
DC 12/24V ±10% |
| Load Voltage Range |
DC 10.2V – 26.4V |
| Max Load Current |
0.2A per point, 2A per common |
| Response Time |
≤1 ms (ON/OFF) |
| Leakage Current |
|
| Insulation Resistance |
≥10 MΩ |
| Internal Consumption |
120 mA |
| External Power Supply |
DC 12/24V, ripple ≤4Vp-p |
| System Compatibility |
MasterLogic-50 PLC, DCS |
| Condition |
Brand New |
| Origin |
USA |
| MOQ |
1 |
Functional Highlights
Honeywell designed the MLE-TP32A with source-type open collector outputs, enabling reliable control of solenoids, relays, and indicators. Its 32-channel configuration simplifies wiring while maintaining strong insulation resistance for electrical safety.
The MLE-TP32A achieves rapid ON/OFF transitions within 1 ms, ensuring precise control in time-critical processes. Its compact 0.4 kg build and small footprint make it ideal for space-constrained control cabinets, while low leakage current and minimal voltage drop contribute to energy efficiency.
Applications and Compatibility
The Honeywell MLE-TP32A suits industries requiring high-density digital outputs, including manufacturing automation, material handling, and process control. Engineers deploy this module in MasterLogic-50 PLC systems to achieve fast switching, reliable connectivity, and efficient cabinet utilization. Its combination of speed, flexibility, and durability makes it a cost-effective solution for modern industrial control environments.
