Description
Overview
The MLE-TN32A Honeywell Output Module is a high-density 32-channel digital output unit designed for the MasterLogic-50 PLC platform. Built for demanding automation environments, it delivers reliable transistor-based sinking outputs with robust electrical isolation, ensuring safe and precise control of industrial devices.
Technical Specifications
| Parameter |
Specification |
| Model Number |
MLE-TN32A |
| Product Type |
Digital Output Module |
| Brand |
Honeywell |
| Condition |
New |
| System Compatibility |
MasterLogic-50 PLC, DCS |
| Output Channels |
32 points |
| Output Type |
Transistor (sinking) |
| Rated Load Voltage |
DC 12/24V |
| Operating Voltage Range |
DC 10.2–26.4V |
| Max Load Current |
0.5A per point, 2A per common |
| Common Configurations |
8 points/COM, 16 points/COM, 32 points/COM |
| Isolation Method |
Photo-coupler |
| Surge Protection |
Zener diode |
| Leakage Current (OFF) |
≤0.1 mA |
| Response Time |
≤1 ms (ON/OFF) |
| Indicators |
LED per channel |
| Connection Options |
Terminal block or 40-pin connector |
| External Power Supply |
DC 12/24V ±10% |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
0.4 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| MOQ |
1 |
| Availability |
In Stock |
Key Features
-
High-density 32-point output for space-efficient control
-
Fast switching response for precise automation sequences
-
Flexible wiring with multiple common configurations
-
Built-in surge protection for stable operation in noisy environments
-
LED indicators for real-time channel monitoring
-
Rugged design suitable for harsh industrial conditions
Application Scenarios
-
Manufacturing automation requiring multiple digital outputs
-
Process control systems with high-speed switching demands
-
Energy-conscious installations needing low power consumption
-
Industrial environments with electrical noise requiring robust isolation
FAQ
Q: What type of loads can the MLE-TN32A drive? A: It supports relays, solenoids, indicators, and other DC-driven devices.
Q: How does the module handle electrical noise? A: Photo-coupler isolation and Zener diode surge protection ensure stable operation in noisy environments.
Q: Is installation complicated? A: No, the module offers both terminal block and 40-pin connector options for simplified wiring and maintenance.
