Overview
The MLE-RY16A from Honeywell is a 16-channel relay output module designed for the MasterLogic-50 PLC series. Built to handle both AC and DC loads, it provides reliable switching performance with robust insulation and long service life. Compact and efficient, this module is ideal for industrial automation systems requiring relay-based outputs for actuators, alarms, and other field devices.
Technical Specifications
-
Model Number: MLE-RY16A
-
Manufacturer: Honeywell
-
Product Type: Digital Relay Output Module
-
System Compatibility: MasterLogic-50 PLC / DCS Systems
-
Condition: Brand New
-
Weight: 0.16 kg
-
Dimensions: 7 × 14 × 14.5 cm
-
HS Code: 8537101190
-
Origin: USA
-
Lead Time: In Stock
-
Minimum Order Quantity (MOQ): 1
-
Status: Active
Electrical and Functional Characteristics
-
Output Channels: 16 relay outputs
-
Rated Load Capacity: DC 24 V / 2 A, AC 220 V / 2 A
-
Operational Range: DC 5 V / 1 mA minimum to AC 250 V or DC 125 V maximum
-
Switching Frequency: Up to 3,600 operations per hour
-
Mechanical Life: > 20 million operations
-
Electrical Life: > 100,000 operations at rated load
-
Response Time: < 10 ms (ON), < 12 ms (OFF)
-
Common Configuration: 8 points per COM group
-
Indicators: LED operation indicators for each channel
-
Wiring: 9-pin terminal block connectors
-
Internal Current Consumption: 420 mA
-
Surge Protection: External surge absorber required
Functional Highlights
-
Provides versatile relay-based switching for AC and DC loads.
-
Long mechanical and electrical life ensures durability in continuous operation.
-
Fast response times suitable for most automation tasks.
-
LED indicators simplify diagnostics and maintenance.
-
Compact design optimized for space-conscious PLC installations.
Application Scenarios
-
Manufacturing plants requiring relay-based actuator control.
-
Energy and utility systems with distributed PLC/DCS integration.
-
Building automation environments needing reliable relay outputs.
-
Process industries requiring mid-speed relay switching for alarms and indicators.
FAQ
Q: How many outputs does the MLE-RY16A provide? A: It offers 16 relay output channels.
Q: What loads can the module handle? A: It supports DC loads up to 24 V / 2 A and AC loads up to 220 V / 2 A.
Q: Does the module include surge protection? A: No, external surge absorbers are required in environments with voltage transients.
Q: How does it compare to MLE-RY08A? A: The MLE-RY16A provides 16 relay outputs, while the MLE-RY08A offers 8 outputs, making the RY16A suitable for higher-density applications.
