Description
Product Overview
The Honeywell MLC-DN32H/DC PWR Supply module supports 32 digital channels for MasterLogic‑50 PLC systems. The compact 7×14×14.5 cm size and 0.4 kg weight simplify installation in dense automation cabinets. The module handles 16 DC 24 V inputs and 16 open‑collector outputs, enabling efficient signal acquisition and device control.
Technical Specifications
| Parameter |
Specification |
| Model Number |
MLC-DN32H/DC |
| Category |
PWR Supply / Digital I/O Module |
| Manufacturer |
Honeywell |
| System |
DCS / MasterLogic‑50 |
| Input Channels |
16 × 24 VDC |
| Output Channels |
16 Open Collector |
| Total Channels |
32 |
| Output Current |
Up to 2 A |
| Instruction Speed |
83 ns per Step |
| Operating Modes |
Repetitive, Cyclic, Interrupt, Constant Scan |
| Programming |
Ladder Diagram / Instruction List |
| Weight |
0.4 kg |
| Dimensions |
7 × 14 × 14.5 cm |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| MOQ |
1 |
Design & Performance
The Honeywell MLC-DN32H/DC processes digital signals with high precision and fast execution. The 83 ns instruction speed supports rapid control loops in demanding automation environments. The module drives up to 2 A per output channel, giving engineers flexibility when connecting actuators and field devices. Its 32‑channel layout consolidates I/O density and reduces panel wiring.
Electrical & Mechanical Characteristics
The Honeywell MLC-DN32H/DC maintains stable operation with a consistent 24 VDC supply. The module’s compact footprint improves cabinet space utilization, while its rugged construction ensures reliable performance in industrial settings. The open‑collector outputs support diverse load types and simplify integration with external devices.
Installation & Integration
Technicians integrate the Honeywell MLC-DN32H/DC easily due to its modular design and compatibility with MasterLogic‑50 PLC systems. The module supports multiple scan modes that allow flexible configuration for different automation strategies. Its programming options enable efficient customization for both simple and complex control tasks.
Applications & Compatibility
The Honeywell MLC-DN32H/DC supports a wide range of industrial applications, including:
-
High‑speed machine automation
-
Distributed digital I/O networks
-
Process control and equipment sequencing
-
Actuator and solenoid control
-
Large‑scale PLC‑based automation systems
Its fast processing and strong output capability make the MLC-DN32H/DC a dependable choice for precise and scalable control architectures.
