Description
Overview
The MC-TDOY62 51204156-175 from Honeywell is a high-density digital output card engineered for distributed control systems (DCS). Designed to provide precise and reliable actuation of field devices, it supports 32 open-collector output channels, making it suitable for valves, actuators, relays, and indicators in demanding industrial automation environments.
Technical Specifications
-
Model Number: MC-TDOY62
-
Part Number: 51204156-175
-
Manufacturer: Honeywell
-
Product Type: Digital Output Card
-
System Compatibility: DCS Systems
-
Condition: Brand New
-
Weight: 0.4 kg
-
Dimensions: 7 × 14 × 14.5 cm
-
HS Code: 8537101190
-
Origin: USA
-
Lead Time: In Stock
-
Minimum Order Quantity (MOQ): 1
-
Status: Active
Electrical and Functional Characteristics
-
Output Channels: 32 open-collector outputs
-
Load Voltage Range: 15–30 VDC
-
Isolation: Galvanic isolation up to 30 VAC or ±42.4 VDC
-
On-State Voltage: ≤ 0.5 V at 0.5A load current
-
Off-State Leakage Current: ≤ 0.5 µA
-
Switching Speed: ≤ 200 ms turn-on/turn-off time
-
Design: Compact and lightweight for easy cabinet integration
Functional Highlights
-
Provides precise digital control for multiple field devices.
-
High channel density reduces cabinet space requirements.
-
Built-in galvanic isolation enhances electrical safety.
-
Low leakage current ensures efficient energy use.
-
Compact design simplifies installation and integration.
Application Scenarios
-
Manufacturing plants requiring reliable actuator control.
-
Process industries managing valves and relays.
-
Machinery automation systems needing high-density outputs.
-
Industrial environments where uptime and safety are critical.
FAQ
Q: How many outputs does the MC-TDOY62 provide? A: It offers 32 open-collector digital output channels.
Q: What voltage range is supported? A: The module operates within 15–30 VDC load voltage.
Q: How does the module ensure safety? A: It includes galvanic isolation to protect connected devices from voltage spikes and noise.
Q: How does it compare to MC-PDOY22? A: The MC-TDOY62 provides 32 outputs with galvanic isolation, while the MC-PDOY22 offers fewer channels but with enhanced diagnostics.
