The Honeywell MC-TAMR04 (Order Code: 51305907-175) is a UCN (Universal Control Network) Low Level Analog Input Multiplexer designed for high-precision data acquisition in industrial process control environments. This field termination assembly (FTA) is engineered to interface directly with thermocouple signals, providing reliable signal conditioning and multiplexing for DCS integration. As a legacy component, this unit is essential for maintaining and extending the operational life of established Honeywell control systems.
Features
- Designed for low-level analog input applications, specifically optimized for thermocouple signal processing.
- High-resolution 24-bit ADC architecture for precise process monitoring.
- Robust common-mode rejection exceeding 140 dB at 50/60 Hz to ensure signal integrity in electrically noisy industrial environments.
- High input impedance (>10 MΩ) to minimize loading effects on sensitive sensors.
- Standardized FTA design for simplified integration into existing Honeywell DCS infrastructure.
Technical Specifications
| Model |
MC-TAMR04 |
| Part Number |
51305907-175 |
| Function |
UCN Low Level Analog Input Multiplexer |
| Resolution |
24-bit ADC |
| Accuracy |
+/- 0.02% of reading +/- 1 uV |
| Common Mode Rejection |
>140 dB @ 50/60 Hz |
| Input Impedance |
>10 MΩ |
| Power Consumption |
15W (typical), 20W (maximum) |
Installation Guidelines
- Ensure the control system is powered down before installing or removing the multiplexer module to prevent electrical damage.
- Mount the unit in a clean, dry, and vibration-free environment, adhering to standard industrial cabinet spacing requirements for heat dissipation.
- Use appropriate shielded cabling for thermocouple connections to maintain signal accuracy and reduce electromagnetic interference (EMI).
- Verify that all field wiring is securely terminated according to the specific wiring diagrams provided in the Honeywell system documentation.
- Maintain proper grounding practices for the FTA chassis to ensure electromagnetic compatibility and safety.
FAQ
Is the Honeywell MC-TAMR04 still in production?
No, this model has been discontinued by the manufacturer. We provide high-quality tested units to support legacy system maintenance.
What is the primary function of this module?
The MC-TAMR04 acts as a low-level analog input multiplexer, primarily used for processing thermocouple signals within a UCN-based Honeywell DCS architecture.
Does this unit require specific maintenance?
Standard maintenance involves periodic inspection of terminal connections for corrosion and ensuring that the module remains free of dust and moisture buildup in the control cabinet.
