The Honeywell MC-TAIH53 (51309138-275) is a 16-channel High Level Analog Input Field Termination Assembly (FTA) designed for integration within the Experion PKS distributed control system. This assembly facilitates the connection of field-based instrumentation, such as pressure, flow, and level transmitters, to the control system's I/O processing modules. It provides a robust interface for critical process loops, ensuring high signal integrity and reliable data transmission in demanding industrial environments.
Features
- 16-channel high-level analog input capacity for efficient signal density.
- Engineered specifically for Honeywell Experion PKS control architectures.
- Optimized for signal termination in petrochemical, power generation, and refinery applications.
- Integrated filtering to mitigate electrical noise and interference from nearby industrial equipment.
- CE-certified design to meet European EMC and operational safety standards.
- Designed for high-density cabinet mounting to optimize control room space.
Applications
This FTA is utilized in continuous process control environments where high-level analog signals must be reliably interfaced with the Experion PKS system. Typical applications include monitoring and controlling critical process variables in flow loops, pressure sensing, temperature monitoring, and analytical instrumentation integration across heavy industrial sectors.
Technical Specifications
| Model |
MC-TAIH53 51309138-275 |
| Series |
Experion PKS |
| Channels |
16 |
| Signal Type |
High Level Analog |
| Power Consumption |
Approx. 5 W |
| Operating Temperature |
0 to 60 deg C |
| Storage Temperature |
-40 to 85 deg C |
| Humidity |
5% to 95% non-condensing |
| Compliance |
CE Mark |
Installation Guidelines
- Ensure the control system is powered down before installing or removing the FTA from the cabinet.
- Mount the assembly in a clean, dry, and vibration-controlled environment as specified for Experion PKS components.
- Follow proper grounding procedures for the cabinet and shield wiring to minimize EMI/RFI impact on analog signals.
- Use appropriate wire gauges for terminal connections to ensure secure signal paths.
- Maintain adequate ventilation within the cabinet to stay within the 0-60 deg C operating temperature range.
FAQ
Is the MC-TAIH53 compatible with other Honeywell systems?
This model is specifically designed for the Experion PKS architecture. Please verify your specific I/O module revision for compatibility.
Does this unit require external power?
The assembly is powered through the system I/O interface; however, verify your specific loop-powered transmitter requirements for external DC supply needs.
