The Honeywell MC-PDIX02 51304485-150 Digital Input Module is an 8-channel unit engineered for precise monitoring of discrete signals in distributed control systems (DCS). Designed with galvanic isolation and robust protective features, it ensures safe and stable operation in demanding industrial environments.
Technical Specifications
| Parameter |
Details |
| Model Number |
MC-PDIX02 51304485-150 |
| Manufacturer |
Honeywell |
| Module Type |
Digital Input Module |
| Condition |
Brand New |
| Dimensions |
7 × 14 × 14.5 cm |
| Weight |
0.66 kg |
| Power Supply Compatibility |
24 VDC / 24 VAC |
| Input Channels |
8 isolated digital inputs |
| Input Voltage Range |
20–30 VDC |
| Pick-Up Voltage |
20 VDC |
| Drop-Out Voltage |
10 VDC |
| Sense Current |
≥ 4.5 mA (ON), ≤ 2.8 mA (OFF) |
| Isolation Rating |
1500 V AC RMS |
| Communication Protocols |
RS-485, Modbus RTU |
| Protective Features |
Conformal coating against humidity and chemical exposure |
| Compliance |
CE certified |
| HS Code |
8537101190 |
| Origin |
USA |
| MOQ |
1 |
| Availability |
In Stock |
| System Integration |
DCS |
| Discontinued |
Active (still supported) |
Functional Highlights
-
Eight isolated digital input channels for reliable signal acquisition.
-
Compatible with both DC and AC low-voltage supplies.
-
RS-485 with Modbus RTU ensures seamless integration into automation networks.
-
Conformal coating provides resistance to harsh environmental conditions.
-
Compact design for easy installation in control cabinets.
-
CE compliance guarantees adherence to international safety standards.
Application Scenarios
-
Machine control systems requiring discrete signal monitoring.
-
Process automation with strict reliability requirements.
-
Safety-critical applications in chemical, energy, and manufacturing industries.
-
Integration into larger DCS architectures with Modbus RTU communication.
FAQ
Q: How many input channels does the module support? A: The MC-PDIX02 51304485-150 provides 8 isolated digital input channels.
Q: What is the isolation rating of the inputs? A: It offers galvanic isolation up to 1500 V AC RMS.
Q: Is this module suitable for AC signals? A: Yes, it supports both 24 VDC and 24 VAC inputs.
Q: What communication protocol is available? A: RS-485 with Modbus RTU is supported for system integration.
