Description
Overview
The MC-PAIH03 51304754-176 Analog Input Module from Honeywell is engineered for precise signal acquisition in distributed control systems (DCS). Designed for the C200 and C300 platforms, it provides high accuracy and robust protection features, ensuring reliable operation in demanding industrial environments.
Technical Specifications
| Parameter |
Details |
| Model Number |
MC-PAIH03 51304754-176 |
| Manufacturer |
Honeywell |
| Module Type |
Analog Input Module |
| Product Range |
Honeywell C200/C300 Series |
| Condition |
Brand New |
| Product Origin |
USA |
| Dimensions |
70 × 140 × 145 mm |
| Weight |
0.58 kg |
| System |
DCS |
| HS Code |
8537101190 |
| MOQ |
1 |
| Lead Time |
In Stock |
| Discontinued |
Active (currently available) |
| Input Channels |
16 |
| Signal Types |
0–20 mA, 4–20 mA |
| Input Impedance |
10 MΩ |
| Accuracy |
±0.1% of span |
| Temperature Drift |
±0.01% of span per °C |
| Operating Temperature |
-40 °C to +70 °C |
| Isolation |
500 V AC |
| Over-voltage Protection |
±30 V continuous |
| Update Rate |
100 ms for all channels |
| Environmental Protection |
Conformal coating, 5–95% RH non-condensing |
Key Features
-
16-channel analog input module supporting industry-standard current signals.
-
High input impedance and ±0.1% accuracy for precise data acquisition.
-
Wide operating temperature range (-40 °C to +70 °C).
-
Strong isolation and over-voltage protection for enhanced safety.
-
Fast update rate (100 ms) for real-time monitoring.
-
Conformal coating for resistance against humidity and contaminants.
-
Seamless integration with Honeywell C200/C300 systems.
Application Scenarios
-
Safety instrumented systems requiring precise analog signal acquisition.
-
Process industries such as oil & gas, chemical, and power generation.
-
High-speed monitoring applications with real-time data requirements.
-
Harsh environments where humidity, temperature extremes, and electrical noise are present.
FAQ
Q: What signals does the MC-PAIH03 51304754-176 support? A: It supports 0–20 mA and 4–20 mA current input signals across 16 channels.
Q: How does the module handle environmental challenges? A: It features conformal coating for humidity resistance and operates from -40 °C to +70 °C.
Q: Is it compatible with Honeywell’s C200/C300 systems? A: Yes, it is fully compatible and integrates seamlessly with these platforms.
