Description
Overview
The Honeywell FTA-T-04 is a 4-channel fail-safe digital input field termination assembly (FTA), engineered for Honeywell Safety Manager and Experion PKS systems. It ensures secure digital signal acquisition with advanced line monitoring and fault detection, providing reliable operation in safety-critical industrial environments.
Functional Description
-
Captures digital signals from switches, pushbuttons, and sensors
-
Provides configurable fail-safe or fail-operate functionality
-
Monitors wiring integrity to detect open or short circuits
-
Compact FTA form factor allows modular rack installation
-
Designed for continuous operation under harsh industrial conditions
Key Features
-
Fail-Safe Design: Maintains safe system operation during faults or power interruptions
-
Line Monitoring: Detects wiring issues to prevent unsafe conditions
-
Compact & Modular: Small footprint integrates easily into existing FTA racks
-
Industrial Reliability: Built to withstand temperature variations, vibration, and EMI
-
System Compatibility: Fully compatible with Honeywell Safety Manager and Experion PKS platforms
Technical Specifications
| Specification |
Details |
| Model |
Honeywell FTA-T-04 |
| Type |
Fail-Safe Digital Input FTA |
| Channels |
4 digital input channels |
| Input Voltage |
24 VDC |
| Input Current |
10 mA |
| Input Resistance |
10 kΩ |
| Line Monitoring |
Detects open/short circuits and wiring faults |
| Fail-Safe Mode |
Configurable fail-safe/fail-operate |
| Dimensions |
95 × 57 × 25 mm |
| Weight |
0.85 lbs |
| Operating Temperature |
-20°C to +65°C |
| Storage Temperature |
-40°C to +105°C |
Applications
-
Safety-critical digital input monitoring in petrochemical, power generation, and manufacturing plants
-
Integration with Honeywell Safety Manager and Experion PKS safety systems
-
Reliable signal acquisition for emergency shutdown (ESD) and interlock systems
FAQ
Q: Can this module detect wiring faults?
A: Yes, the FTA-T-04 includes line monitoring to detect open circuits, short circuits, and other wiring issues.
Q: Is it compatible with hot-swappable racks?
A: It fits standard FTA racks but should be installed according to system guidelines; hot-swap is not indicated for this model.
Q: What environments is it rated for?
A: It operates from -20°C to +65°C and withstands harsh industrial conditions.
