Honeywell FC-TUIO11 Safety Universal I/O Module

Configured for universal field signal execution in Honeywell Safety Manager and Fail Safe Controller systems, the Honeywell FC-TUIO11 (FC-TUIO11 Safety Universal I/O Module) provides direct physical and electrical interface functions for safety-related input and output channels.

Hardware Specifications

Parameter	Specification
Model	FC-TUIO11
Brand	Honeywell
Product Type	Safety Universal I/O Module
Origin	USA
Weight	0.4 kg
Dimensions	19.1 x 18.8 x 6.5 cm
Operating Temp	Not specified
Power Consumption	1.22 W at 24 VDC
Power Supply	24 VDC
Rated Current	55 mA at 24 VDC
Maximum Safe Voltage (Um)	250 V
Uo	25.2 V
Io	113.13 mA
Po	712.7 mW
Tariff Code	8537101190

Process Control Signal Interface Characteristics

The FC-TUIO11 supports universal I/O signal handling within Honeywell safety control architectures. The module provides field circuit connection capability with defined electrical safety parameters, including 250 V maximum safe voltage and intrinsically safe output limits of 25.2 V, 113.13 mA, and 712.7 mW.

Furthermore, Honeywell Safety Manager configurations can apply channel-to-channel isolation practices to maintain separation between field wiring circuits. The module design supports integration with process instrumentation interfaces where signal conditioning and controlled electrical characteristics are required.

Frequently Asked Questions

Q: What power supply does the Honeywell FC-TUIO11 require?
A: The FC-TUIO11 operates from a 24 VDC power supply and consumes 55 mA at rated voltage.

Q: What are the maximum electrical safety parameters of the FC-TUIO11?
A: The module specifies a maximum safe voltage (Um) of 250 V, with Uo of 25.2 V, Io of 113.13 mA, and Po of 712.7 mW.

Q: Can the FC-TUIO11 be installed in redundant safety controller systems?
A: The module is designed for Honeywell safety control platforms. Redundancy configuration depends on the controller architecture and system engineering requirements.

Field Installation Guidelines

• Install the FC-TUIO11 inside the designated Honeywell safety controller chassis according to system hardware documentation.
• Verify that the 24 VDC supply polarity and voltage level match the module requirements before energizing the system.
• Separate field signal wiring from high-voltage power cables to reduce electrical interference.
• Connect cable shields according to the site grounding design and applicable industrial installation standards.
• Confirm terminal wiring, channel assignment, and safety circuit configuration before commissioning.
• Check the module electrical parameters against connected field devices to maintain compliance with the specified Um, Uo, Io, and Po limits.

Specifications

• Brand: Honeywell

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
