Honeywell FC-TSDO-0824C Safe Digital Output Module Configured for safe discrete output control in Honeywell safety system architectures, the Honeywell FC-TSDO-0824C...
Read more
Available on working days between 9:00 am to 6:00 pm
Email us: sales2@industriaxplc.com
Available 24/7 for inquiries and support
Description
Honeywell FC-TSDO-0824C Safe Digital Output Module
Configured for safe discrete output control in Honeywell safety system architectures, the Honeywell FC-TSDO-0824C (FC-TSDO-0824C Safe Digital Output Module) provides direct electrical execution for field actuator switching.
Hardware Specifications
Parameter
Specification
Model
FC-TSDO-0824C
Brand
Honeywell
Product Type
Safe Digital Output Modules
Origin
USA
Weight
0.08 kg
Dimensions
Estimated shipping size: 7 x 6 x 5.8 cm
Approvals
CE, TUV, UL, CSA, FM
Number of Channels
8 channels
Maximum Voltage
36 VDC according to IEC 1010 (1990)
Maximum Continuous Current Per Channel
1.5 A
Maximum Wire Diameter
2.5 mm2 (AWG 14)
Module Function
Safe digital output signal control
Signal Type
Discrete DC output
Safe Digital Output Control and SIS Integration
The FC-TSDO-0824C provides eight digital output channels for controlling external field devices within Honeywell safety control environments. Moreover, the module transfers safety-related switching commands from the controller to connected actuators and devices.
The output channels support DC loads with a maximum voltage rating of 36 VDC and a continuous current capability of 1.5 A per channel. Therefore, the module can interface with compatible field equipment requiring controlled discrete power switching.
In addition, the module supports safety system installation requirements through recognized industrial approvals, including CE, TUV, UL, CSA, and FM certifications.
Safety System Output Interface Features
The FC-TSDO-0824C functions as an output interface between Honeywell safety controllers and field execution devices. Moreover, the module design supports controlled signal transmission for applications requiring defined output states.
The digital output architecture provides channel-level field connection capability through dedicated wiring. Therefore, proper terminal selection and cable sizing remain important during system installation.
The module supports wire sizes up to 2.5 mm2 (AWG 14). In addition, engineers should verify connected device current requirements before applying field loads to each output channel.
Frequently Asked Questions
Q: How many output channels does the Honeywell FC-TSDO-0824C provide? A: The FC-TSDO-0824C provides 8 safe digital output channels for field device control.
Q: What is the maximum current rating for each output channel? A: Each channel supports a maximum continuous current of 1.5 A.
Q: What is the maximum voltage supported by the FC-TSDO-0824C output channels? A: The module supports a maximum voltage of 36 VDC according to IEC 1010 (1990).
Field Installation Guidelines
Install the FC-TSDO-0824C within the approved Honeywell safety system hardware configuration according to engineering documentation.
Verify field actuator specifications before connecting output wiring. Confirm that voltage levels and current requirements remain within the module operating limits.
Use correctly sized conductors and maintain proper terminal tightening procedures during installation. Moreover, separate output wiring from high-voltage circuits to reduce electrical interference.
Check all safety logic assignments and output channel configurations before commissioning. Confirm each connected field device responds according to the configured safety application requirements.
