Honeywell FC-TERM-0001 IO Extender Module

Configured for signal expansion and field I/O interface extension in Honeywell safety control platforms, the Honeywell FC-TERM-0001 (TERM-0001 IO Extender Module) provides direct physical and electrical execution for distributed I/O signal connection.

Hardware Specifications

Parameter	Specification
Model	FC-TERM-0001
Spare Model	TERM-0001
Brand	Honeywell
Product Type	IO Extender Module
Origin	USA
Place of Shipment	Xiamen, China
Weight	Not specified
Dimensions	3.7 x 1.9 x 0.7 cm
Operating Temp	-40 deg C to +70 deg C
Storage Temp	-50 deg C to +85 deg C
Power Consumption	2.5 W typical
Power Requirements	24 VDC (18-36 VDC)
Rated Current	50 mA
Isolation Voltage	1500 VAC
Channel Capacity	16 points
Signal Types	DI / DO / AI / AO
Humidity	5-95% RH, condensing
Vibration Resistance	5 g @ 10-500 Hz
Approvals	CE, TUV, UL, CSA, FM
Tariff Code	8537101190

Channel Isolation and Process Signal Interface

The FC-TERM-0001 supports mixed field signal connection through a 16-point I/O expansion interface. The module accepts digital input, digital output, analog input, and analog output signal types within compatible Honeywell control architectures.

Furthermore, the module applies channel-to-channel isolation methods to separate field circuits and reduce electrical interference between connected signal paths. The 1500 VAC isolation rating supports industrial cabinet installation where multiple field loops operate within the same enclosure.

For process instrumentation connections, the module architecture supports standard analog signal handling requirements. Therefore, it can integrate with control systems that use conventional field transmitter and actuator signal structures.

Frequently Asked Questions

Q: What signal types does the FC-TERM-0001 support?
A: The FC-TERM-0001 supports DI, DO, AI, and AO field signal types through a 16-point I/O expansion interface.

Q: What power input range does the module require?
A: The module operates with a 24 VDC input supply and supports an input range from 18 VDC to 36 VDC.

Q: Can the FC-TERM-0001 operate in high temperature environments?
A: The module supports operation from -40 deg C to +70 deg C and storage conditions from -50 deg C to +85 deg C.

Field Installation Guidelines

• Install the FC-TERM-0001 inside an approved industrial control cabinet with proper mechanical support.
• Verify the 24 VDC supply polarity before connecting field power terminals.
• Separate analog signal wiring from high-current power cables to reduce electromagnetic interference.
• Connect cable shields according to the control system grounding design and maintain a single reference point where required.
• Confirm terminal assignments before connecting DI, DO, AI, and AO field circuits.
• Avoid exceeding the specified environmental limits during operation and storage.
• Inspect wiring insulation and termination quality before system commissioning.
