The DC-TDOB01 Digital Output Module from Honeywell is a 32-channel relay-based output unit designed for Experion® PKS and FSC systems. Built for demanding industrial environments, it provides galvanically isolated dry contacts suitable for both low and high voltage applications.
Technical Specifications
-
Model: DC-TDOB01
-
Manufacturer: Honeywell
-
Product Type: Digital Output Module
-
Condition: Brand New
-
Availability: In Stock
-
Weight: 0.4 kg
-
Dimensions: 18.8 × 19.1 × 6.5 cm
-
HS Code: 8537101190
-
Minimum Order Quantity: 1
-
Origin: USA
-
System Compatibility: DCS / FSC System
-
Operating Temperature: -40°C to +70°C
-
Isolation Rating: 1500V
-
Output Channels: 32, jumper-selectable Form-A (NO) or Form-B (NC)
-
Load Voltage Range: 15–30 VDC
-
Typical Output: 24 VDC at 0.5 A
-
Switching Response: 10 ms
-
Protection: Integrated counter EMF snubbing, short-circuit protection
-
Communication Interface: Ethernet router
-
Mounting: Vertical cabinet installation with tilt design for heat dissipation
-
Design: Series C I/O with integrated electronics and field terminations
Functional Highlights
-
Socketed relays with LED indicators for channel status monitoring.
-
Compact housing with detachable two-level terminals for simplified installation.
-
Field power supplied directly via IOTA interface, reducing external wiring.
-
Redundant configuration support when paired with secondary IOM modules.
-
Maintenance-friendly design with visual status alerts for quick diagnostics.
Application Scenarios
-
Power generation facilities requiring reliable relay-based digital outputs.
-
Oil & gas process control systems with high isolation requirements.
-
Chemical processing plants needing fast switching and robust protection.
-
Critical infrastructure environments where redundancy and stability are essential.
FAQ
Q: Can the DC-TDOB01 operate in extreme temperature ranges? A: Yes, it is rated for -40°C to +70°C, ensuring reliable performance in harsh environments.
Q: Does the module support redundant operation? A: Yes, redundancy is achieved when paired with a secondary IOM module.
Q: How does it simplify installation compared to older Honeywell modules? A: The Series C I/O design integrates electronics and field terminations, eliminating the need for separate chassis.
