Description
Overview
The DC-TCNT01 Safety Controller from Honeywell is part of the SC S300 family, designed for high-precision pulse counting and flow measurement in safety-critical process automation. Certified to SIL3 standards, this module integrates seamlessly with Experion® PKS and FSC systems, delivering reliable performance in demanding industrial environments.
Technical Specifications
-
Model: DC-TCNT01
-
Manufacturer: Honeywell
-
Product Type: SC S300 Safety Controller (SIL3)
-
Condition: Brand New
-
Availability: In Stock
-
Weight: 0.36 kg
-
Dimensions: 43 × 23 × 25 cm
-
HS Code: 8537101190
-
Minimum Order Quantity: 1
-
Origin: USA (global distribution from Xiamen, China)
-
System Compatibility: DCS / FSC System
-
Input Channels: 8 pulse counter channels
-
Input Voltage Range: 5–30 VDC
-
Frequency Response: Up to 10 kHz
-
Isolation: 1500 V
-
Operating Temperature: -40°C to +70°C
-
Mounting: Chassis-less design via I/O Termination Assemblies (IOTA)
-
Controller Integration: Compatible with Honeywell C300 controllers (redundant and non-redundant)
-
Communication Service: Ethernet router
Functional Highlights
-
Quadrature counting capability for turbine flow meters and rotary encoders.
-
Advanced counting algorithms with configurable linear and quadrature modes.
-
SIL3-compliant architecture ensures safety integrity in critical applications.
-
Compact form factor with high-density signal processing.
-
Built-in diagnostics and status indicators simplify maintenance.
-
Plug-and-play connectivity reduces installation complexity.
Application Scenarios
-
Custody transfer operations requiring precise flow measurement.
-
Oil & gas facilities with turbine flow meters and pulse-generating devices.
-
Power generation plants needing redundant safety controllers.
-
Chemical processing environments requiring robust and accurate pulse counting.
FAQ
Q: How many channels does the DC-TCNT01 support? A: It supports 8 pulse counter channels with quadrature functionality.
Q: What is the maximum frequency response? A: The module can process signals up to 10 kHz.
Q: Is the DC-TCNT01 suitable for hazardous environments? A: Yes, it operates reliably from -40°C to +70°C with 1500 V isolation.
Q: Can this module be used with redundant controllers? A: Yes, it integrates with Honeywell C300 controllers in both redundant and non-redundant configurations.
