Description
Overview
The DC-TAOX11 Analog Output Module from Honeywell is part of the Series C I/O family, designed for distributed control systems (DCS) within the Experion PKS platform. This compact module integrates electronics and field terminations into a single IOTA-mounted package, eliminating the need for separate chassis while delivering high-density analog output capability.
Technical Specifications
| Parameter |
Value |
| Model Number |
DC-TAOX11 |
| Product Type |
Analog Output Module |
| Manufacturer |
Honeywell |
| Condition |
Brand New |
| Product Range |
Experion PKS / Series C I/O |
| System Compatibility |
DCS |
| Dimensions |
29.4 × 12 × 17 cm |
| Weight |
0.38 kg |
| HS Code |
8537101190 |
| Origin |
USA |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
| Lifecycle Status |
Active |
| Output Channels |
16 analog outputs |
| Signal Type |
4–20 mA with HART communication support |
| Accuracy |
±0.1% |
| Power Supply |
Field power via IOTA base (no external supply required) |
| Redundancy |
Built-in redundancy when paired with a second module |
| Terminal Design |
Two-level detachable terminals for simplified wiring |
| Protection |
Integrated circuit protection (no external fuses required) |
| Mounting |
Vertical cabinet mounting with optimized heat dissipation |
| Communication Service |
Ethernet Router |
Key Features
-
16-channel analog output with HART-enabled communication
-
Compact IOTA-mounted design eliminates separate chassis requirements
-
±0.1% accuracy maintained even in high-density installations
-
Built-in redundancy without external cabling for fault-tolerant operation
-
Detachable two-level terminal blocks simplify wiring and maintenance
-
Integrated circuit protection reduces external hardware needs
-
Optimized thermal management for reliable vertical cabinet mounting
-
Rugged construction ensures long-term durability in demanding environments
Application Scenarios
-
Oil and gas facilities requiring precise actuator and valve control
-
Chemical processing plants with high-density output requirements
-
Power generation systems needing redundant analog output modules
-
Industrial automation projects where space optimization and reliability are critical
FAQ
Q: How many output channels does the DC-TAOX11 provide? A: It supports 16 analog output channels with HART communication.
Q: Does the module require an external power supply? A: No, it receives field power directly through the IOTA base.
Q: Can redundancy be achieved with this module? A: Yes, redundancy is supported by pairing a second module without additional cabling.
Q: What accuracy does the DC-TAOX11 maintain? A: It delivers ±0.1% accuracy across all channels.
